We would like to introduce a case where we provided design for assembly jigs and proposals for improving part accuracy, and received high praise for the quality of the prototypes.
We will introduce a case where we conducted a study on the prototyping and mass production of a modular weight roller and resolved the issues. Due to its different shape compared to conventional designs and the assembly nature of the parts, there was limited knowledge from customers. Even at the prototyping stage, there were challenges such as warping during assembly and unstable dimensional accuracy due to variations in pressure input. Since an outer dimension tolerance of ±0.05mm was required during assembly, we proposed the creation of dedicated assembly jigs for each type of prototype and aimed to improve part accuracy. Although the required specifications were not met during prototyping, the variations were reduced to less than half of the initial levels, and there were no issues in the actual machines or durability test results. 【Case Overview】 ■Challenges - Even at the prototyping stage, there was warping during assembly, and dimensional accuracy was unstable due to variations in pressure input. ■Results - Although the required specifications were not met during prototyping, the variations were reduced to less than half of the initial levels, and there were no issues in the actual machines or durability test results. *For more details, please contact us.
Inquire About This Product
basic information
【Other Case Summary】 ■Request Details - Prototype and mass production of an assembled weight roller ■Required Specifications - Dimensional tolerance during assembly of ±0.05mm *Please contact us for more details.
Price range
Delivery Time
Applications/Examples of results
For more details, please contact us.
