Achieving nanoscale "actual measurement" with optical "vertical focus."
In research institutions, it is required to accurately measure the fine structures of surfaces and evaluate the properties of materials. In particular, shape measurement at the nanoscale plays an important role in the development of new materials and the research of surface treatment technologies. Traditional measurement methods have faced challenges such as long measurement times and limitations in measurement accuracy. Our Real Nano 3D measurement system enables actual measurements at the nanoscale through high-speed continuous scanning and vertical focus technology, contributing to the efficiency of research. 【Application Scenarios】 - Surface roughness and shape measurement in materials science research - Quality evaluation of semiconductor devices - Research and development of coating technologies - Surface property evaluation of medical devices 【Effects of Implementation】 - Acquisition of high-precision surface shape data - Reduction of research time - Improvement of research outcomes - Compatibility with diverse materials
Inquire About This Product
basic information
【Features】 - High-speed continuous scanning - Optical profiler - Actual measurement (without stitching) - Easy sample preparation - Nanovia's unique new method "Multicolor Light Sensor Measurement" 【Our Strengths】 We handle products adopted by world-class companies and provide rapid support comparable to domestic manufacturers.
Price information
Please feel free to contact us.
Delivery Time
※Please feel free to contact us.
Applications/Examples of results
◎Distortion and curvature measured ◎High-speed processing of large areas ◎No refocusing required ◎Sharp images ◎No sample preprocessing ◎Measurement possible for any color ▶Non-contact measurement ▶Maximum vertical resolution = 1nm ▶Maximum surface angle = 87° ▶No data stitching ◎Surface roughness ■Ra measurement in 1 second ■Various materials and surface complexities (3D or 2D) ■Automotive roughness finishing standards ◎Texture/Grain ■Isotropic and anisotropic surfaces ■Analysis of unevenness ◎Surface profile ■Direct comparison with CAD geometry ■Curvature, radius, angle ■Lateral dimensions ■Study of drill bits ■Cutting tool research ◎Step height/Thickness ■Direct measurement of transparent materials ■Thickness of transparent films and coatings up to 20nm ■Steps from 20nm to 25mm ◎Volume/Area ■Differential surface and volume loss ■Corrosion analysis ■Motif and granularity analysis ◎Flatness/Warping ■Flatness 1um to 500mm (without correction)
