Dimension layout as intended by the designer! Reduces drawing creation time.
In the construction industry, accurate dimensioning in drawing creation is essential. However, manually placing dimensions can be time-consuming and prone to errors. This burden increases significantly, especially for drawings with complex shapes or those requiring numerous dimensions. Raksun, as an AutoCAD add-in application, assists in dimension placement according to the designer's intent. By simply selecting a shape and pressing a button, it automatically places necessary dimensions such as outline dimensions and hole spacing. This leads to improved efficiency and quality in drawing creation. 【Usage Scenarios】 - Dimensioning architectural drawings - Adding dimensions to renovation drawings - Modifying dimensions during design changes 【Benefits of Implementation】 - Reduced man-hours: Significantly decreases the effort required for manual dimension input - Stable quality: Reduces human errors and minimizes variations among different designers - Smoother collaboration: Prevents discrepancies in interpretation during subsequent processes by using common drawing rules "Raksun" can be utilized independently, and it also allows for flexible customization to fit the unique design environment of each customer. By incorporating the specific dimension creation rules established by each company into the system, a more practical automated environment can be built. Please feel free to consult with us.
Inquire About This Product
Related Videos
basic information
【Features】 - Automatically place dimensions just by selecting a shape and pressing a button - Supports dimension placement in line with the designer's intent - Dramatically reduces manual labor - Compatible with AutoCAD 2025 and 2026 - Compatible with AutoCAD Architecture, Mechanical, MEP 2025 and 2026 【Our Strengths】 Since our establishment in 1984, we have faced various challenges in the manufacturing industry. We combine our customers' know-how with 3D shape processing technology to provide solutions that are useful on-site.
Price range
Delivery Time
Applications/Examples of results
It automatically displays dimensions by specifying the presence or absence of dimension output and the display position.
