Proceeding with layout changes and equipment placement considerations without understanding the current situation. Providing accurate current data through 3D scanning to improve decision-making accuracy and speed.
Troubles that often arise during equipment installation or line changes, such as "not fitting" or "interfering." Many of these issues are caused by insufficient accuracy in understanding the current situation. Based on current data obtained through 3D scanning, we enable accurate layout planning using CAD. Addressing these challenges: ● Unable to determine in advance whether equipment can be delivered and installed during installation ● Insufficient interference checks leading to problems in later processes ● Time-consuming on-site surveys and measurements for current situation verification ● Inability to make high-accuracy judgments in the initial stages of layout planning ● Rework due to discrepancies in understanding within the company and with external parties Approach and duration: ● On-site scanning: half a day to 1 day ● Data conversion and organization: 3 to 5 business days ● Delivery: approximately 1 week
Inquire About This Product
basic information
Price estimate: 250,000 to 300,000 yen (adjustable depending on range and scale) This is a package for preparing "current data" that can be examined with CAD before proceeding with layout changes based on "experience" or "on-site intuition."
Price range
Delivery Time
Applications/Examples of results
What can be done with this package: ● Obtain the current state of the factory through 3D scanning ● Provide 3D CAD data that can be used for layout considerations ● Enable layout planning and interference checks in your own CAD environment ● Determine whether "design is feasible" before creating drawings
catalog（1）
Download All Catalogs
Company information
Our company offers services centered around drones (unmanned aerial vehicles). With many years of experience as professionals in drone operation, we cater to various needs, including construction consulting areas such as bridge inspections and chimney inspections, surveying work, 8K aerial photography, and consulting for the operation and management of in-house drones. Please feel free to contact us if you have any requests.
