Fully Automatic Double-Sided Crimping Machine for Industrial Machinery 'Alpha520'
Fully automatic crimping machine for both ends that supports different batch sizes and wire sizes for civilian use!
This is a fully automatic crimping machine specialized for industrial use. It is ideal for batch sizes ranging from large to small, as well as for a wide variety of wire lengths, cross-sectional areas, and wire end processing. It allows for intuitive operation while being controlled by the proven Komax HMI system. We provide solutions that cater to your processing needs along with a diverse range of processing modules. 【Features】 〇 Industrial machinery and consumer devices leveraging the proven track record of the Komax Group's Alpha series 〇 An ideal fully automatic crimping machine with high versatility that can handle any challenge, whether the production volume is high or low, and regardless of whether the wires are delicate, thick, or very short 〇 Easy operation with the intuitive control system of Komax HMI 〇 Even inexperienced operators can start operating with a short training period 〇 High-speed and high-precision processing
Inquire About This Product
Related Videos
basic information
【Technical Data】 Internal wire diameter: 0.13 to 6 mm² (AWG 30 to 10)* Wire insertion speed: Maximum 10 m/s (33 ft/s) Maximum wire outer diameter: Max. 5.1 mm Processing length range: 20 – 30 mm Full strip: 0.1 – 30 mm Semi-strip: 0.1 – 29 mm Crimping force: 1 – 22 kN Number of equipment mounted on 1 side / 2 sides: 2 / 2 (2 units on each side) Noise: < 80 dB (without crimping tool) Input power supply: 3 × 208 – 480 V / 50 – 60 Hz / 5.6 k VA Air pressure: 0.5 – 0.8 MPa (73 – 116 psi) Air consumption for crimping both ends: <7 m³/h Air consumption for crimping waterproof plugs on both ends: <11 m³/h Weight: (including 2 crimp modules) 1.30 t *Consultation required. Depends on the material of the wire. After verification with sample processing, we can also accommodate wires of 0.13 mm² (AWG 26). For more details, please feel free to contact us or download the catalog.
Price information
Prices may vary depending on specifications, so please feel free to contact us.
Delivery Time
※Delivery dates may vary depending on the specifications, so please feel free to contact us.
Applications/Examples of results
It is a device for the livelihood and industrial machinery sectors. It automatically crimp processes both ends of the wire.
catalog（6）
Download All Catalogs
Company information
In August 2022, Komax and Schloniger merged, and Schloniger became a member of the Komax Group. Schloniger Japan handles all Komax Group products in Japan. The solutions offered by the Komax Group overwhelmingly surpass those of other companies in terms of performance and cost-effectiveness. They also have significant features, including very high repeat processing accuracy and stable quality, high reliability and long equipment lifespan, ease of operation (user-friendly), short setup times, high versatility, strong product development capabilities, and comprehensive solution capabilities.
