Expand your expression with the power of static electricity!
In the world of art expression, there is always a demand for new methods of expression and combinations of materials. The technology that uses static electricity to fix materials expands the possibilities of expression that could not be achieved with conventional adhesives. For example, it allows for the three-dimensional arrangement of films and thin materials, making temporary exhibitions and installations easy to realize. Our electrostatic gun is a tool that enables these expressions. 【Usage Scenarios】 * Installation works * Temporary material fixation at exhibitions * Temporary fixing in three-dimensional modeling 【Effects of Implementation】 * Development of new methods of expression * Free arrangement of materials * Increased efficiency in exhibition work
Inquire About This Product
Related Videos
basic information
【Features】 * A charging device used in combination with the "GT series" compact high-voltage power supply controller. * The grip part has a grounding structure, making it easy to discharge any static electricity from the human body, allowing for safe use. * ON/OFF operation can be performed with a trigger at hand, even from a distance of 5m from the controller (extendable up to 20m). * The shape of the tip electrode can be changed for versatile use. * A battery-operated charging device that easily generates static electricity (25kV). * A compact and user-friendly charging device suitable for educational materials and simple charging tests on-site. * Can be used for multiple purposes by exchanging the tip electrode (compatible with GC90 accessories). 【Our Strengths】 We have a proven track record of contributing to society through the development and manufacturing of electrical and electronic control equipment over many years. Utilizing high-voltage control technology, we respond to the diverse needs of our customers.
Price range
Delivery Time
Applications/Examples of results
【Examples of Use】 [Corona Charging Gun GC90] ■ Adsorbing paper, foil, plastic sheets, etc. onto metal plates ■ Testing the charging performance of paper, plastic sheets, fibers, etc. ■ Using the repulsion of like charges to open fibers, etc. ■ Suction and adsorption of plastic powders and various ceramic powders ■ Charging and coating of fine powders ■ Power supply applications for electret production ■ Power supply applications for electrospinning devices for nanofiber production [Battery-Powered Charging Gun GC25B] ■ Simple experiments utilizing static electricity ■ Charging for confirming deionization effects ■ Educational purposes (Franklin motor, electrostatic pendulum, charging of Leyden jars, etc.) ■ Suction and adsorption of various fine particles and powders ■ Adsorption of paper, foil, plastic sheets, etc. ■ Opening of fibers using the repulsion of like charges * In addition to the above, a wide range of applications is possible. * For more details, please refer to the catalog or feel free to contact us.
catalog（7）
Download All Catalogs
Company information
We have contributed to society through the development and manufacturing of electrical and electronic control devices for many years. In recent years, we have entered the fields of high voltage control, fluid control, and automatic control of mechatronic devices, focusing on the development and production of eco-friendly, resource-saving, and high-quality products, which have been highly regarded and attracted attention from many industries.
