Unnoticed, it embraces cultural assets. PICLIA piezoelectric wire sensor.
The PICLIA piezoelectric wire sensor is a sensing solution designed to quietly monitor the preservation environment and condition changes of cultural properties. It enables unobtrusive monitoring with minimal installation burden, ensuring that the value of delicate structures and exhibits is not compromised. By capturing vibrations and subtle changes, it supports the preservation work of cultural properties by allowing for early detection of signs of abnormalities. It delivers a sense of security without excessive human intervention—this is the role of the PICLIA piezoelectric wire sensor. 【Usage Scenarios】 - Detection of subtle vibrations in the ground surrounding cultural properties - Vibration monitoring during restoration and reinforcement work - Safety confirmation through monitoring ground movement during nearby construction 【Benefits of Implementation】 - Real-time acquisition of extensive vibration data - Early detection of abnormalities in cultural properties and surrounding ground - Increased efficiency and cost reduction in investigation and monitoring tasks - Provision of decision-making materials to advance preservation plans with peace of mind while minimizing impact on cultural properties.
Inquire About This Product
Related Videos
basic information
**Features** ♦ Wire-shaped piezoelectric sensor ♦ Wide bandwidth (0.1 to several MHz), capable of observing vibrations over a wide area rather than just points ⇒ Collects low to high frequency data collectively for overall preventive maintenance of equipment ♦ Acquires pressure, vibration, shock, and vital signals with a thin wire ♦ Responds to physical deformation, can be mounted to conform to shapes like curved surfaces and gloves ⇒ Application examples: industrial equipment, medical, wearable, sports, etc. ♦ High sensitivity acquisition of weak signals such as heartbeat and respiration (Min. 0.003N) ♦ No power supply required ⇒ Contributes to low power consumption systems ♦ Same structure as coaxial cables, capable of sensing with low noise ♦ Usable in harsh environments such as water, oil/solvents, and high temperatures ♦ Environmentally compatible from -40 to 120°C, 10 million cycles of bend resistance ⇒ High durability ♦ Integrated molding with resin (up to 120°C) including urethane, TPU, silicone, epoxy, etc.
Price range
Delivery Time
※Please contact us.
Applications/Examples of results
【Application Examples】 ■ Medical and Care (Monitoring): Behavior and health monitoring using chairs/beds/foot mats (disinfection and sterilization compatible) ■ Industrial Equipment (Measurement, Predictive Maintenance): Vibration monitoring of equipment, molds, and parts ⇒ Rotation, vibration, leak (Operating environment -40℃ to 120℃, 0.1Hz to ultrasonic range) ■ Resin Parts (Predictive Maintenance): Vibration, rotation, leak, and accumulation in parts where magnet attachment is difficult, such as bearings, valves, and resin piping Integrated molding (EVA, urethane, TPU, silicone, epoxy, etc.) ■ Wearable (Measurement): Vibration monitoring in glove form (quality control, sports) ■ Robotics (Tactile): Robot motion (motion errors, arm vibration), cable integration ■ Automotive (Autonomous Driving): Detection of health abnormalities (vital signs and center of gravity shifts), bumper collision detection ■ Security (Crime Prevention): Intrusion detection using wired networks, pest control ■ Others (Structural Deterioration Detection): Deterioration detection of pillars and beams of important cultural properties *Installed by wrapping without drilling holes *For more details, please refer to the catalog or feel free to contact us.
