In the resin and on the surface. The PICLIA wire sensor captures invisible changes.
The PICLIA wire sensor is a piezoelectric wire-type sensor that is easy to install in narrow spaces and curved shapes, where it is difficult to use conventional acceleration sensors that are fixed with screws or magnets. In addition to being embedded in resin products, it can also be mounted on the product surface, enabling flexible sensor placement according to application and design conditions. Generally, resin has a tendency to dampen vibrations, but by embedding it near the vibration source or mounting it appropriately on the surface, it is possible to capture fine vibrations and changes. This allows for a broad understanding of the condition of resin products, from monitoring internal states to confirming surface behavior. 【Usage Scenarios】 - State monitoring through embedding in the interior of resin products - Vibration and change detection through surface mounting on resin products - Flexible sensor installation in resin products with narrow spaces or curved shapes - Integration and external monitoring in areas difficult for conventional sensors 【Benefits of Implementation】 - Supports both embedding and surface mounting, enhancing design and operational flexibility - Ensures sensing accuracy even when resin tends to dampen vibrations through appropriate placement - Captures fine vibrations and changes, contributing to early detection of anomalies - Provides insights from both internal states and surface behavior, contributing to quality stabilization and improved reliability.
Inquire About This Product
Related Videos
basic information
**Features** ♦ Wire-shaped piezoelectric sensor ♦ Wide bandwidth (0.1 to several MHz), capable of observing vibrations over a wide area rather than just a point ⇒ Collects low to high frequency data collectively for overall preventive maintenance of equipment ♦ Thin wire captures pressure, vibration, shock, and vital signals ♦ Responds to physical deformation and can be mounted to conform to shapes such as curved surfaces and gloves ⇒ Application examples: industrial equipment, medical, wearable, sports, etc. ♦ Highly sensitive acquisition of weak signals like heartbeat and respiration (Min. 0.003N) ♦ No power supply required ⇒ Contributes to low power consumption systems ♦ Same structure as coaxial cables, enabling low-noise sensing ♦ Usable in harsh environments such as water, oil/solvents, and high temperatures ♦ Environmentally compatible from -40 to 120°C, with a bending resistance of 10 million cycles ⇒ High durability ♦ Integrated molding with resin (up to 120°C) including urethane, TPU, silicone, epoxy, etc.
Price range
Delivery Time
※Please contact us.
Applications/Examples of results
【Application Examples】 ■ Medical and Nursing Care (Monitoring): Behavior and health monitoring with chairs/beds/foot mats (disinfection and sterilization compatible) ■ Industrial Equipment (Measurement, Predictive Maintenance): Vibration monitoring of equipment, molds, and parts ⇒ Rotation, vibration, leak (-40℃ to 120℃ environment, 0.1Hz to ultrasonic range) ■ Resin Parts (Predictive Maintenance): Vibration and rotation in parts where magnet attachment is difficult, such as bearings, valves, and resin piping Leakage and accumulation Integrated molding (EVA, urethane, TPU, silicone, epoxy, etc.) ■ Wearable (Measurement): Vibration monitoring in glove form (quality control, sports) ■ Robotics (Tactile): Robot movements (motion errors, arm vibrations), integrated cables ■ Automotive (Autonomous Driving): Detection of abnormal physical conditions (vital signs and center of gravity shifts), bumper collision detection ■ Security (Crime Prevention): Intrusion detection with wired networks, pest control ■ Others (Structural Deterioration Detection): Deterioration detection of pillars and beams of important cultural properties *Installed by wrapping without drilling holes *For more details, please refer to the catalog or feel free to contact us.
