Narrow, bendable, and embedable. Therefore, don't miss it. Detects vibrations with high sensitivity and fast response.
The PICLIA wire sensor is a piezoelectric wire-type sensor that can flexibly adapt to narrow spaces and curved surfaces where screw fastening or magnetic fixation is difficult. It can be easily integrated into areas such as the outer circumference of valves and piping, joints, and support sections, where traditional accelerometers are challenging to install, allowing for direct capture of vibrations and state changes in the vicinity. It is particularly effective for monitoring areas that have been difficult to grasp in the past, such as subtle vibrations associated with fluid passage, valve opening and closing operations, and abnormal signs in piping systems. This enables a more direct understanding of the internal conditions of piping and valves, contributing to early detection of anomalies and preventive maintenance. 【Usage Scenarios】 Monitoring vibrations and state changes by installing on the valve body or the outer circumference of piping. Embedded monitoring around piping and valves in narrow spaces or with curved shapes. Capturing subtle vibrations associated with fluid fluctuations and opening and closing operations. 【Benefits of Implementation】 By measuring near the source of vibration, it is easier to capture subtle changes before attenuation. It provides information closer to the internal conditions of piping and valves, contributing to improved accuracy in state assessment. It accommodates shapes where screw fastening or magnetic fixation is difficult, ensuring design flexibility. It captures signs of anomalies early, contributing to more efficient maintenance and reduced risk of equipment downtime.
Inquire About This Product
Related Videos
basic information
【Features】 ♦ Wire-shaped piezoelectric sensor ♦ Wide bandwidth (0.1 to several MHz), capable of observing vibrations over a wide area rather than just a point ⇒ Collects low to high frequencies in one go, contributing to the preventive maintenance of the entire equipment ♦ Captures pressure, vibration, shock, and vital signals with a thin wire ♦ Responds to physical deformation, can be mounted to conform to shapes like curved surfaces and gloves ⇒ Application examples: industrial equipment, medical, wearable, sports, etc. ♦ High sensitivity to weak signals like heartbeat and respiration (Min. 0.003N) ♦ No power supply required ⇒ Contributes to low power consumption systems ♦ Same structure as coaxial cables, capable of sensing with low noise ♦ Usable in harsh environments such as water, oil, solvents, and high temperatures ♦ Compatible with environments from -40 to 120°C, 10 million cycles of bend resistance ⇒ High durability ♦ Integrated molding with resin (up to 120°C) including urethane, TPU, silicone, epoxy, etc.
Price range
Delivery Time
※Please contact us.
Applications/Examples of results
【Application Examples】 ■ Medical and Nursing Care (Monitoring): Behavior and health monitoring with chairs/beds/foot mats (disinfection and sterilization compatible) ■ Industrial Equipment (Measurement, Predictive Maintenance): Vibration monitoring of equipment, molds, and parts ⇒ Rotation, vibration, leak (Operating in environments from -40℃ to 120℃, 0.1Hz to ultrasonic range) ■ Resin Parts (Predictive Maintenance): Vibration, rotation, leak, and accumulation in parts where magnet attachment is difficult, such as bearings, valves, and resin piping Integrated molding (EVA, urethane, TPU, silicone, epoxy, etc.) ■ Wearable (Measurement): Vibration monitoring in glove form (quality control, sports) ■ Robotics (Tactile): Robot motion (motion errors, arm vibration), integrated cables ■ Automotive (Autonomous Driving): Detection of health abnormalities (vital signs and center of gravity shifts), bumper collision detection ■ Security (Crime Prevention): Intrusion detection using wired networks, pest control ■ Others (Structural Deterioration Detection): Deterioration detection of pillars and beams in important cultural properties *Installed by wrapping without drilling holes *For more details, please refer to the catalog or feel free to contact us.
