Utilizing the T-die extrusion technology we have developed over many years, we accept everything from development to contract manufacturing, even for small lots!
Do you have any experience with wanting to form fine shapes on the film surface, wanting to create a special compound resin into a film, having resin pellets available but no film grade in the lineup, being turned away due to small lot sizes, being able to prototype but not mass-produce, being unable to film due to soft materials or tacky materials, or being unable to laminate in a clean room? If you have any issues with T-die extrusion, please consult with us first. From prototyping with a small test machine to production with mass production machines, we will do our utmost to meet your needs! <General Environment> - Small extrusion test device with an effective width of approximately 210mm (single-layer to multi-layer, up to 3 types and 5 layers) - Mass production machine for extrusion lamination with an effective width from 620mm to a maximum of 2,150mm (multiple units) *Additional equipment: Co-extrusion, sand feed device, double-sided tandem, corona treatment, after corona, frame treatment, detectors, etc. <Clean Room> - Medium mass production machine with an effective width of approximately 650mm (single-layer) - Large mass production machine with an effective width of approximately 1,300mm (multi-layer) - Mass production machine for extrusion lamination with an effective width of 800mm to 1,400mm (AC treatment, sand feed device, single-sided tandem)
Inquire About This Product
basic information
- Extrusion Performance Resins: PC, COP, COC, PET, PBT, PEN, PMMA, PSU, PEI, POM, PA, ABS, PS, MS, SPS, TPU, TPX, PE, PP, EVA, various elastomers, biomass materials, biodegradable resins, special compound resins, and many others. - Examples of Composition: - Single-layer films (single resin, composite resin) - Multi-layer films (2 types 2 layers to 3 types 5 layers) - Forming films (extrusion, coating) - Laminated laminates (extrusion laminates onto substrates such as films, paper, non-woven fabrics, etc.) - Sand laminates (paper/extruded resin/barrier film, film/extruded resin/metal foil, separator/extruded resin/separator, etc.) - Evaluation Equipment: - Laser microscope - Microscope - 2D dimensional measurement - Total light transmittance and haze measurement - DSC measurement - Moisture content measurement - Water vapor permeability measurement - Tensile testing machine - Heat sealer - Pencil hardness measurement - High-temperature testing - High-humidity testing *For more details, please refer to the PDF materials or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
Our processed products are used in a wide range of industries, including food packaging, beverage cups, medical and hygiene materials, construction materials, agricultural materials, labels, process paper, mold prevention, antibacterial, pest repellent, electronic components, automotive, optical materials, solar panels, semiconductor-related components, and bio-life science-related components, among others.
catalog（1）
Download All Catalogs
Company information
Since its establishment in 1950, Goyou Paper Co., Ltd. has been engaged in the manufacturing and sales of waterproof and moisture-proof processed paper, which is essential for distribution systems. While capturing the needs of a changing era, we have consistently strived for advanced technological development and the evolution of original products under the spirit of "being the only one." Aiming to establish advanced processing technologies required for the next generation, we will continue our research and refinement, pioneering business development in a market with infinite possibilities to carve out the future.
