A new grade that balances BH characteristics and iron loss! We are offering a limited-time free gift along with the introduction of the existing 'Somaloy(R)' grades!
A new grade of soft magnetic composite material (SMC material) Somaloy(R) has been introduced! It has undergone significant evolution, including the adoption of an insulation coating that is fundamentally different from previous versions. Please make use of it for various motor cores and more. (The soft magnetic composite material 'Somaloy(R)' is our trademark.) ■ New Grade Name Somaloy(R)700 7P ■ Overview - Somaloy(R) is a soft magnetic composite material with an insulation coating applied to pure iron powder. - The new grade achieves lower iron loss than before while maintaining high BH characteristics through improvements to the base pure iron powder and the development of a new insulation coating. - It also offers higher heat resistance and lower CO2 emissions compared to the previous grade. From June to the end of July 2026, you can download the new grade preliminary data sheet and existing grade introduction materials for free for a limited time.
Inquire About This Product
Related Videos
basic information
■Somaloy(R) Features - A coating of insulating film is applied to pure iron powder, achieving high efficiency in high-frequency ranges due to low eddy current loss characteristics! - High compressibility allows for high permeability. - Enables three-dimensional magnetic circuit design, achieving miniaturization, lightweight, and cost reduction of products. - Complex shapes can be formed without post-processing through net shaping (three-dimensional mechanical shapes that can be formed with uniaxial pressure). - Low CO2 emissions from the material support sustainable product development. ■New Grade Somaloy(R)700 7P Overview - #100 mesh iron powder + 7P coating. - Comparable compressibility and BH characteristics (magnetic flux density, permeability) to #40 mesh powder. - Iron loss at 1T, 1kHz is approximately 10% lower than Somaloy 700HR 5P (=low loss grade so far). - Higher heat resistance than conventional insulating coatings. - Lower CO2 emissions than existing grades. - Further high strength and high permeability possible through optimization of heat treatment conditions (under development). Please refer to the attached materials for comparison data with conventional grades.
Price range
Delivery Time
Applications/Examples of results
【Usage Examples】 We have a proven track record of using it as core material for various products. ■ Motor Applications - Drive Motors - Auxiliary Motors - In-Wheel Motors ■ Passive Component Applications such as Reactors On-Board Reactors Off-Board Reactors Choke Coils Ignition Coils Injectors, etc. We contribute to electrification by proposing/providing materials that meet your usage conditions, ranging from several hundred Hz to about 100 kHz.
Line up（1）
| Model number | overview |
|---|---|
| Somaloy(R)700 7P | The new grade achieves even lower iron loss than before. |
catalog（2）
Download All Catalogs
Company information
Heganas Corporation started as a coal mining company in Heganas village in southern Sweden over 220 years ago in 1797. Since then, it has continuously led the global market as a pioneer in iron powder and metal powder, growing into the world's largest manufacturer of metal powders with an annual production capacity of 500,000 tons. Our vision is to inspire the industry to make more with less, improving resource efficiency and leading a wave of positive change. Heganas' metal powders are adopted as excellent materials for manufacturing parts and various other applications, serving as crucial materials in many sectors of the industry. As the range of applications expands, a wide variety of products with different chemical compositions, particle sizes, and shapes are being developed, with Heganas continuing to take a leading role in these developments. We offer a rich and comprehensive product range that surpasses any other metal powder manufacturer, supplying over 3,500 types of products from 17 locations worldwide. Heganas Corporation is globally active across the group, aiming to achieve climate neutrality in all operations by 2037 to contribute to sustainable growth.
