Reduce chip clogging and improve processing effort and tool life.
Are you facing challenges such as chip clogging in the inner diameter during machining of work machine spindle parts, negative effects on the work surface and tools due to chip elongation, and processing stoppages that accompany these issues? To address these problems, HORN has launched a new boring tool, the "U Breaker Super Mini." This product demonstrates exceptional chip fragmentation capabilities, reducing the hassle of processing stoppages while also extending tool life. 【Application Scenarios】 - Inner diameter machining of steel and stainless steel - Small diameter boring - Machining where chip handling is a challenge 【Benefits of Implementation】 - Reduction of processing stoppages due to chip clogging - Mitigation of chip impact on the work surface and tools - Improvement in tool life
Inquire About This Product
Related Videos
basic information
【Features】 - Compatible with pilot hole diameters of φ 4.0, 5.0, and 6.0 mm (new products for φ 4.0 and φ 5.0 mm will be added starting December 2024) - Eliminates chip clogging even with steel and stainless steel - Usable with existing tool holders - Achieves low-cost mass production compared to laser and grinding products through breaker formation via sintering 【Our Strengths】 Founded in 1910, we have been a specialized trading company for machine tools, supporting manufacturing sites for many years. With partnerships with 500 domestic suppliers and 20 overseas companies primarily in Europe, our mission is to provide customers with progressive and high-quality services. In addition to the sale of cutting tools and machine tools, we also develop and sell our original brand "i-TOOL," and import and sell overseas products, pursuing "value creation" that contributes to our customers' profits.
Price range
Delivery Time
Applications/Examples of results
■ S45C Vc：100m/min ap：0.2mm f：0.03mm/rev ■ SUS304 Vc：80m/min ap：0.2mm f：0.03mm/rev
Line up（8）
| Model number | overview |
|---|---|
| RS105.1833.2.4.U20 IG35/TH35 | 【Bottom hole diameter φ 4.0 mm ～】 Insert total length: 30mm |
| RS105.1833.3.4.U20 IG35/TH35 | 【Bottom hole diameter φ 4.0 mm ～】 Insert total length: 35mm |
| RS105.1833.2.5.U20 IG35/TH35 | 【Drill hole diameter φ 5.0 mm ～】 Insert total length: 30mm |
| RS105.1833.3.5.U20 IG35/TH35 | 【Bottom hole diameter φ 5.0 mm ～】 Insert total length: 35mm |
| RS105.1833.4.5.U20 IG35/TH35 | 【Bottom hole diameter φ 5.0 mm ～】 Insert total length: 40mm |
| RS105.1833.2.6.U20 IG35/TH35 | 【Bottom hole diameter φ 6.0 mm ～】 Insert total length: 30 mm |
| RS105.1833.3.6.U20 IG35/TH35 | 【Bottom hole diameter φ 6.0 mm ～】 Insert total length: 35 mm |
| RS105.1833.4.6.U20 IG35/TH35 | 【Bottom hole diameter φ 6.0 mm ～】 Insert total length: 40 mm |
