"Waterproof type" solar radiation wireless data logger [outdoor]
HD35EDWRTC/HD35EDLWRTC: Waterproof Solar Radiation Wireless Data Logger [Outdoor] by Senseka
Waterproof housing specification! Records solar radiation and sunshine duration, wirelessly transmits measurement data to the main unit!
The HD35EDWRTC/HD35EDLWRTC is an outdoor waterproof wireless data logger for solar radiation from the Senseca wireless data logging system "HD35 series." ■ IP67 waterproof housing specification, suitable for outdoor solar radiation monitoring ■ Equipped with one input with M12 connector for solar sensors ■ Stores 42,000 data points in internal memory ■ Wirelessly transmits recorded data to the master unit at regular intervals or on demand ■ Capable of calculating daily cumulative solar radiation (Wh/m²) ■ Supports calculations of sunshine duration in addition to solar radiation measurement ■ Features an audible alarm with a built-in buzzer ■ Configurable with software HD35AP-S ■ Powered by a built-in battery, also supports mast mounting and outdoor installation options ■ The version for Japan comes with an integrated external antenna *For more details, please download the PDF or feel free to contact us.*
Inquire About This Product
basic information
【Solar Radiation】 Sensor: Thermopile Measurement Range: 0–2000W/m² Resolution: 1W/m² Sensitivity: Configurable in mV/(kW/m²) units 【Main Unit】 Wireless Frequency: 915.9–929.7MHz Transmission Distance: 300m with internal antenna, 500m with external antenna in line of sight Logging Interval: 1, 2, 5, 10, 15, 30 seconds / 1, 2, 5, 10, 15, 30, 60 minutes Power Supply: Built-in 3.6V thionyl chloride lithium battery, non-rechargeable, battery size AA, 2-pin Molex5264 connector Battery Life: Approximately 2 years (without repeater, measurement interval of 5 seconds, logging interval of 30 seconds) Operating Conditions: -20 to +70℃ / 0 to 100% RH, no condensation Dimensions: 129×80×55mm (excluding probe and external antenna) Weight: Approximately 250g Housing Material: Polycarbonate Protection Rating: IP67 *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
● Food service (frozen containers, refrigeration and low-temperature storage, food processing and transportation) ● Health-related (storage of pharmaceuticals, vaccines, and blood, incubators, monitoring of operating rooms) ● Greenhouses and other agricultural applications ● Environmental analysis (air quality, meteorology, and hydrology) ● Monitoring of solar panels and power generation ● Monitoring of museums and archives ● Transportation of fragile products and corrosion (monitoring of shocks through acceleration measurement) ● Air conditioning industry ● Clean rooms ● Research and laboratories ● Processes in the industrial sector ● Buildings, offices, schools *For more details, please download the PDF or feel free to contact us.*
