"Waterproof type" soil temperature and moisture wireless data logger [outdoor]
HD35EDWS...TC/HD35EDLWS...TC: Waterproof Soil Temperature and Moisture Wireless Data Logger [Outdoor] by Senseka
Waterproof housing specification! Records soil temperature and moisture at 1 to 3 points, wirelessly transmits measurement data to the main unit!
The HD35EDWS...TC/HD35EDLWS...TC is an outdoor waterproof soil temperature and moisture wireless data logger from Senseca's "HD35 Series" wireless data logging system. ■ IP67 waterproof housing specification, suitable for outdoor soil temperature and moisture monitoring ■ Compatible with soil temperature and moisture composite probes HP3510.1/HP3510.2 ■ Depending on the model, options for 1ch/2ch/3ch M12 connector inputs are available ■ Measurement data can be stored in internal memory for 26,000 to 52,000 data points ■ Recorded data can be wirelessly transmitted to the master unit at regular intervals or on demand ■ Supports audible alarms via a built-in buzzer ■ Configurable with software HD35AP-S ■ Powered by a built-in battery, also supports outdoor installation options *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
【Humidity】 Sensor: Capacitive type Measurement range: 0–100% VWC (Volumetric Water Content) Accuracy: ±3% (0–50% VWC, standard mineral soil up to 5 mS/cm, at 23°C) Sensor operating temperature: -40 to +60°C 【Temperature】 Sensor: NTC 10KΩ (at 25°C) Measurement range: -40 to +105°C Accuracy: ±0.5°C 【Main Unit】 Wireless frequency: 915.9–929.7 MHz Transmission distance: 300 m with internal antenna, 500 m with external antenna (line of sight) Logging interval: 1, 2, 5, 10, 15, 30 seconds / 1, 2, 5, 10, 15, 30, 60 minutes Power supply: Built-in 3.6V thionyl lithium battery, non-rechargeable, battery size AA, 2-pin Molex 5264 connector Battery life: Approximately 2 years (without repeater, measurement interval of 5 seconds, logging interval of 30 seconds) Operating conditions: -20 to +70°C / 0 to 100% RH, no condensation Dimensions: 129×80×55 mm (excluding probe and external antenna) Weight: Approximately 250 g Housing material: Polycarbonate Protection rating: IP67 *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
● Food services (frozen containers, refrigeration and low-temperature storage, food processing and transportation) ● Health-related (storage of pharmaceuticals, vaccines, blood, incubators, monitoring of operating rooms) ● Greenhouses and other agricultural applications ● Environmental analysis (air quality, meteorology, and hydrology) ● Monitoring of solar panels and power generation ● Monitoring of museums and archives ● Transportation of fragile products (monitoring of shocks through acceleration measurement) ● Air conditioning industry ● Clean rooms ● Research and laboratories ● Processes in the industrial sector ● Buildings, offices, schools *For more details, please download the PDF or feel free to contact us.*
