8-port Gigabit + 4-port 10GbE SFP, Layer 2+/Layer 3 managed switch, extended temperature range -40 to 75°C.
**Intrising DAS-8G-4X Features** - 8-port Gigabit RJ45 + 4-port 10GbE SFP+ equipped - Layer 2+/Layer 3 managed switch - Redundant network support with ERPS (G.8032), RSTP/MSTP - Dual power input support - Supports DHCP Server/Client/Relay, VLAN, QoS, ACL - Management features via SNMP v1/v2c/v3, Web GUI, CLI, SSH - Operating temperature range -40 to 75°C (-I model) - DIN rail and wall mount compatible (wall mount is optional)
Inquire About This Product
basic information
Specifications ■ Interface 10/100/1000Base-T×8 1G/2.5G/10GbE SFP+×4 ■ Switching Function Layer2+/Layer3 ■ Redundancy ERPS (G.8032), RSTP, MSTP ■ Power Supply Dual 16.8–56VDC (standard) or 9–36VDC (24V model) ■ Power Consumption Maximum 27W ■ Dimensions • 95.84 (W) x 135 (D) x 152 (H) mm ■ Mounting Method DIN rail and wall mount compatible (wall mount is optional) ■ Protection Rating IP30 ■ Environment Operating Temperature -20–60℃ (standard), -40–75℃ (-I model) ■ MTBF 586082.5 hours ■ Certification FCC CE Stability: • IEC 60068-2-32 (Free fall) • IEC 60068-2-27 (Shock) • IEC 60068-2-6 (Vibration)
Price information
Open price
Price range
P2
Delivery Time
P4
Applications/Examples of results
Cold outdoor, offshore, railway, ships, oil refinery, coal mine, pharmaceutical company, various factories, meteorological station.
Line up（4）
| Model number | overview |
|---|---|
| DAS-8G-4X | Dual 16.8~56 VDC input , -20°C~60°C / -4°F~140°F |
| DAS-8G-4X-I | Dual 16.8~56 VDC input , -40°C~75°C / -40°F~167°F |
| DAS-8G-4X-24V | Dual 9~36 VDC input , -20°C~60°C / -4°F~140°F |
| DAS-8G-4X-I-24V | Dual 9 ~ 36 VDC input , -40°C~75°C / -40°F~167°F |
