8-port Gigabit RJ45 + 4-port 10GbE SFP+, 8-port PoE++ power supply function, extended temperature range -40 to 75°C.
【Intrising DAS-8GHP-4X Features】 ■ Equipped with 8-port Gigabit RJ45 + 4-port 10GbE SFP+ ■ 8-port PoE++ power supply function (IEEE 802.3af/at/bt, up to 60W/port) ■ Maximum PoE power capacity of 240W (standard model) ■ Layer 2+/Layer 3 managed switch ■ Redundant network support with ERPS (G.8032), RSTP/MSTP ■ Dual power input support ■ Supports DHCP Server/Client/Relay, VLAN, QoS, ACL ■ Network management via SNMP v1/v2c/v3, Web GUI, CLI, SSH ■ Operating temperature range of -40 to 75°C (-I model) ■ Supports DIN rail and wall mounting
Inquire About This Product
basic information
Specifications ■Interface 10/100/1000Base-T×8 1G/2.5G/10GbE SFP+×4 ■PoE PoE Standards IEEE 802.3af / at / bt (PoE++) PoE Power Supply Capability Maximum 60W/port PoE Power Capacity Maximum 240W (standard model), 80W (24TV/24V model) ■Switching Function Layer2+/Layer3 ■Redundancy ERPS (G.8032), RSTP, MSTP ■Power Supply Dual 44–56VDC (standard), 16.8–56VDC (24TV), 9–36VDC (24V) ■Dimensions • 95.84mm (W) x 135mm (D) x 163mm (H) ■Mounting Method DIN rail and wall mount compatible (wall mount is optional) ■Protection Rating IP30 ■Environment Operating Temperature -20–60℃ (standard), -40–75℃ (-I model) ■MTBF 586082.5 hours
Price information
Open price
Price range
P2
Delivery Time
P4
Applications/Examples of results
Cold outdoor, offshore, railway, vessels, oil refinery, coal mine, pharmaceutical company, various factories, meteorological station.
Line up（6）
| Model number | overview |
|---|---|
| DAS-8GHP-4X | Dual 44 ~ 56 VDC input , -20°C~60°C / -4°F~140°F , PoE per port up to 60 W; PoE total budget 240 W |
| DAS-8GHP-4X-I | Dual 44 ~ 56 VDC input , -40°C~75°C / -40°F~167°F , PoE per port up to 60 W; PoE total budget 240 W |
| DAS-8GHP-4X-24TV | Dual 16.8 ~ 56 VDC input , -20°C~60°C / -4°F~140°F , PoE per port up to 60 W; PoE total budget 80 W |
| DAS-8GHP-4X-24TV-I | Dual 16.8 ~ 56 VDC input , -40°C~75°C / -40°F~167°F , PoE per port up to 60 W; PoE total budget 80 W |
| DAS-8GHP-4X-24V | Dual 9 ~ 36 VDC input , -20°C~60°C / -4°F~140°F , PoE per port up to 60 W; PoE total budget 80 W |
| DAS-8GHP-4X-24V-I | Dual 9 ~ 36 VDC input , -40°C~75°C / -40°F~167°F , PoE per port up to 60 W; PoE total budget 80 W |
