Domestic production, a sense of security. A flexible design that allows you to choose the Ag:AgCl ratio.
In the field of printed electronics, high-precision and reliable conductive materials are required to integrate diverse functions. Particularly in applications such as bioelectrodes and various electrochemical sensors, finely tuning the characteristics of electrodes and achieving unique shapes and wiring patterns is essential for improving device performance. It is important to eliminate supply uncertainties and delivery risks associated with overseas products and to enhance design flexibility through in-house production. The Peltron K-398X series is a domestically produced screen printing silver/silver chloride conductive paste that meets these needs. 【Usage Scenarios】 - Integration of functions in bioelectrodes - Fabrication of various electrochemical sensors - Customization of reference electrodes - Printing on thin and flexible substrates 【Benefits of Implementation】 - Stable supply and short delivery times from domestic production - Optimization of characteristics through selection of Ag:AgCl ratios - Realization of function integration through flexible electrode design - Cost reduction and lead time shortening through in-house production
Inquire About This Product
basic information
【Features】 - Easy procurement and short delivery times achieved through domestic formulation - Multiple grades with different Ag:AgCl mixing ratios available - Electrode shapes, areas, and wiring patterns can be freely designed - High adhesion and durability due to the use of epoxy resin binder - Supports continuous production through screen printing 【Our Strengths】 Since our establishment in 1970, we have been providing products that finely meet customer needs based on the technology and know-how we have cultivated as a resin formulator. In addition to epoxy products, we offer a wide range of insulating materials, coating materials, and conductive paste materials based on urethane and silicone, delivering products not only within Japan but also worldwide across various fields such as electronic components, automotive-related parts, and industrial equipment parts. We are particularly skilled in formulating resins tailored to the specific characteristics required by our customers.
Price information
Prices may vary for products containing silver. Please inquire with us directly.
Delivery Time
Applications/Examples of results
[Medical and Biometric Sensing] Epidermal electrodes, electrocardiogram (ECG) electrodes, electroencephalogram (EEG) electrodes, electromyogram (EMG) electrodes, defibrillator (AED) pads, electrodes for electrical therapy, blood glucose monitoring (SMBG/FMG/CGM) electrodes [Electrochemistry and Sensors] General reference electrodes, electrochemical sensor reference electrodes for pH, ions, ORP, etc. [Environment and Agriculture] Environmental monitoring, plant bio-potential measurement (collaborative research with universities) etc.
Line up（5）
| Model number | overview |
|---|---|
| K-3980 | Silver: Silver chloride ratio = 6:4 (weight ratio) |
| K-3981 | Silver: Silver chloride ratio = 9:1 (weight ratio) |
| K-3982 | Silver: Silver chloride ratio = 6:4 (weight ratio) |
| K-3983 | Silver: Silver chloride ratio = 5:5 (weight ratio) |
| K-3984 | Silver: Silver chloride ratio = 4:6 (weight ratio) |
catalog（2）
Download All Catalogs![[Technical Data] Silver/Silver Chloride Paste Peltron® K-3980 (Japanese)](https://image.mono.ipros.com/public/catalog/image/2096080/IPROS672995648028744686.jpeg?w=120&h=170)
Company information
Since our establishment in 1970, we have consistently built our products based on the technology and know-how we have cultivated as a resin formulator, while carefully responding to our customers' needs. We offer a lineup that includes not only epoxy products (liquid and powder) but also insulating materials based on urethane and silicone, as well as coating materials and conductive paste materials. Our applications range widely, primarily focusing on electronic components, but also including automotive parts, industrial equipment parts, sports goods, and everyday items. We deliver our products not only within Japan but also to Europe, China, Southeast Asia, and around the world.
