Domestic peace of mind, with the freedom to choose the Ag:AgCl ratio in the design.
In the field of IoT sensors, particularly for environmental measurement, there is a demand for stable long-term measurements and adaptability to various installation environments. The selection of electrode materials, which influences sensor performance, is a crucial factor as it directly impacts measurement accuracy and reliability. Relying on overseas products may introduce risks such as supply instability and delivery delays, which can affect development and mass production plans. Our silver/silver chloride paste K-398X series addresses these challenges by providing stable domestic supply and the flexibility to choose optimal characteristics according to specific purposes. 【Usage Scenarios】 - Outdoor environmental measurement sensors - Wearable environmental monitoring devices - Agricultural soil moisture and pH sensors - Water quality monitoring systems 【Benefits of Implementation】 - Achieves stable procurement and short delivery times compared to overseas products - Effective as a BCP and second-source measure - Allows selection of Ag:AgCl ratios tailored to measurement methods and required characteristics - Supports free design of electrode shapes and wiring patterns
Inquire About This Product
basic information
【Features】 - Domestic screen printing paste formulated in Japan - Multiple grades with different mixing ratios of silver and silver chloride - Flexible design for electrode shapes, areas, and wiring patterns - Compatible with printing on thin, flexible substrates - Uses epoxy resin binder considering adhesion to substrates and durability after curing 【Our Strengths】 Since our establishment in 1970, we have been providing products that finely meet customer needs based on the technology and know-how we have cultivated as a resin formulator. In addition to epoxy products, we offer a wide range of materials including urethane, silicone-based insulating materials, coating materials, and conductive paste materials, serving various applications such as electronic components, automotive parts, and industrial equipment parts for customers both domestically and internationally. We particularly excel in customizing resin formulations according to customer requests.
Price information
Prices may vary for products containing silver. Please inquire with us directly.
Delivery Time
Applications/Examples of results
[Medical and Biometric Sensing] Epidermal electrodes, electrocardiogram (ECG) electrodes, electroencephalogram (EEG) electrodes, electromyogram (EMG) electrodes, defibrillator (AED) pads, electrodes for electrical therapy, blood glucose monitoring (SMBG/FMG/CGM) electrodes [Electrochemistry and Sensors] General reference electrodes, electrochemical sensor reference electrodes for pH, ions, ORP, etc. [Environment and Agriculture] Environmental monitoring, plant bio-potential measurement (collaborative research with universities) etc.
Line up（5）
| Model number | overview |
|---|---|
| K-3980 | Silver: Silver chloride ratio = 6:4 (weight ratio) |
| K-3981 | Silver: Silver chloride ratio = 9:1 (weight ratio) |
| K-3982 | Silver: Silver chloride ratio = 6:4 (weight ratio) |
| K-3983 | Silver: Silver chloride ratio = 5:5 (weight ratio) |
| K-3984 | Silver: Silver chloride ratio = 4:6 (weight ratio) |
catalog（2）
Download All Catalogs![[Technical Data] Silver/Silver Chloride Paste Peltron® K-3980 (Japanese)](https://image.mono.ipros.com/public/catalog/image/2096080/IPROS672995648028744686.jpeg?w=120&h=170)
