Silver Chloride Paste for Biopotential Electrodes K-398X Series | Domestic | For Printing
Peltron®
Printing materials for ECG, EEG, and EMG electrodes.
For the formation of biopotential electrodes such as ECG, EEG, EMG, and AED pads. By screen printing silver/silver chloride paste, it is possible to design electrode shapes and areas tailored to specific applications, aiding in the in-house production of development products and prototypes. The Peltron K-398X series is a silver/silver chloride (Ag/AgCl) conductive paste for screen printing, formulated domestically in Japan. ○ Being domestically produced allows for easy procurement and short lead times. Compared to overseas products, supply is stable, making it ideal for BCP and second-source measures. ○ Multiple grades with different mixing ratios of silver and silver chloride are available. Depending on the measurement method, desired characteristics, and usage duration, you can select the optimal grade from reference electrodes to biopotential electrodes. ○ Electrode shapes, areas, and wiring patterns can be freely designed, making it applicable not only to biopotential electrodes but also to reference electrodes and various electrochemical sensors. * For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
Do you have any of the following concerns? - Want to eliminate supply uncertainties and delivery risks for overseas products - Want to manufacture unique electrode shapes, areas, and wiring patterns in-house - Want to print on thin, flexible substrates - Want to choose the silver/silver chloride ratio according to the measurement method The Peltron K-398X series is a silver/silver chloride conductive paste designed for continuous production using screen printing. It uses an epoxy resin binder that considers adhesion to the substrate and durability after curing. The standard curing conditions are 130°C for 20 minutes. Printing conditions, film thickness, and curing conditions need to be verified according to the substrate and electrode design. Sample sales are available starting from 100g. *All values are representative. Official specifications, measurement methods, and warranty scope will be provided in individual technical documents.
Price information
Prices may vary for products containing silver. Please inquire directly with us.
Delivery Time
Applications/Examples of results
[Medical and Biometric Sensing] Epidermal electrodes, electrocardiogram (ECG) electrodes, electroencephalogram (EEG) electrodes, electromyogram (EMG) electrodes, defibrillator (AED) pads, electrodes for electrical therapy, blood glucose monitoring (SMBG/FMG/CGM) electrodes [Electrochemistry and Sensors] General reference electrodes, electrochemical sensor reference electrodes for pH, ions, ORP, etc. [Environment and Agriculture] Environmental monitoring, plant bio-potential measurement (collaborative research with universities) etc.
Detailed information
-
Pelnox publishes a glossary of terms related to bioelectrodes on its official website.
-
Pelnox has published a glossary of terms related to bioelectrodes on its official website.
-
Pelnox publishes a glossary of terms related to bioelectrodes on its official website.
Line up（5）
| Model number | overview |
|---|---|
| K-3980 | Silver: Silver chloride ratio = 60:40 (weight ratio) |
| K-3981 | Silver: Silver chloride ratio = 90:10 (weight ratio) |
| K-3982 | Silver: Silver chloride ratio = 60:40 (weight ratio) |
| K-3983 | Silver: Silver chloride ratio = 50:50 (weight ratio) |
| K-3984 | Silver: Silver chloride ratio = 40:60 (weight ratio) |
catalog（2）
Download All Catalogs![[Technical Data] Silver/Silver Chloride Paste Peltron® K-3980 (Japanese)](https://image.mono.ipros.com/public/catalog/image/2096080/IPROS672995648028744686.jpeg?w=120&h=170)
