Easier to consider shapes and formulations for different applications.
When you want to prototype different electrodes for various applications such as chemical electrodes, bioelectrodes, and environmental sensors. You can combine different grades with varying Ag:AgCl ratios and printing designs to facilitate comparative evaluations of multiple specifications. The Peltron K-398X series is a conductive paste for screen printing made from silver/silver chloride (Ag/AgCl) that is formulated domestically in Japan. - Being domestically produced, it is easy to procure and has a short delivery time. Compared to overseas products, the supply is stable, making it ideal for BCP and second source measures. - Multiple grades with different mixing ratios of silver and silver chloride are available. Depending on the measurement method, desired characteristics, and usage period, you can select the optimal grade for reference electrodes to bioelectrodes. - You can freely design the electrode shape, area, and wiring pattern, making it applicable not only to bioelectrodes but also to reference electrodes and various electrochemical sensors. *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
Do you have any of these concerns? - Want to eliminate supply uncertainties and delivery risks for overseas products - Want to manufacture unique electrode shapes, areas, and wiring patterns in-house - Want to print on thin, flexible substrates - Want to choose the silver/silver chloride ratio according to the measurement method The Peltron K-398X series is a silver/silver chloride conductive paste designed for continuous production using screen printing. It uses an epoxy resin binder that considers adhesion to the substrate and durability after curing. The standard curing conditions are 130°C for 20 minutes. Printing conditions, film thickness, and curing conditions need to be confirmed according to the substrate and electrode design. Sample sales are available starting from 100g. *All values are representative. Official specifications, measurement methods, and warranty coverage will be provided in individual technical documents.
Price information
Prices may vary for products containing silver. Please inquire with us directly.
Delivery Time
Applications/Examples of results
[Medical and Biometric Sensing] Epidermal electrodes, electrocardiogram (ECG) electrodes, electroencephalogram (EEG) electrodes, electromyogram (EMG) electrodes, defibrillator (AED) pads, electrodes for electrical therapy, blood glucose monitoring (SMBG/FMG/CGM) electrodes [Electrochemistry and Sensors] General reference electrodes, electrochemical sensor reference electrodes for pH, ions, ORP, etc. [Environment and Agriculture] Environmental monitoring, plant bio-potential measurement (collaborative research with universities) etc.
Detailed information
-
Pelnox has published a glossary of terms related to bioelectrodes on its official website.
-
Pelnox has published a glossary of terms related to bioelectrodes on its official website.
-
Pelnox has published a glossary of terms related to bioelectrodes on its official website.
Line up（5）
| Model number | overview |
|---|---|
| K-3980 | Silver: Silver chloride ratio = 60:40 (weight ratio) |
| K-3981 | Silver: Silver chloride ratio = 90:10 (weight ratio) |
| K-3982 | Silver: Silver chloride ratio = 60:40 (weight ratio) |
| K-3983 | Silver: Silver chloride ratio = 50:50 (weight ratio) |
| K-3984 | Silver: Silver chloride ratio = 40:60 (weight ratio) |
