SUS304 stainless steel casing, Atom x7433RE/x7835RE, operating temperature -40 to 70°C, fanless operation, waterproof IP69K.
【IEI SWBOX-ASL Features】 ■ Width 226.4 × Height 81 × Depth 178.5 mm ■ Fully waterproof and dustproof, compliant with IP69K ■ Equipped with Intel Atom x7433RE/x7835RE, fanless ■ DDR5-4800MHz memory, supports up to 16GB ■ 2.5GbE ×2 ports (M12 X-Code) ■ 1GbE fiber LAN support (optional) ■ HDMI ×2 ports ■ DDR5-4800MHz memory, supports up to 16GB ■ 2.5-inch SATA HDD/SSD bay ■ Expansion slots: M.2 M-Key ×1, M.2 E-Key ×1, M.2 B-Key ×1, SIM card slot ×1 ■ Supports storage and communication function expansion via M.2 ■ Wide power input range of DC 10–28V ■ Wide temperature operation range of -40 to 70℃ ■ DIN rail / wall mount compatible ■ Compatible with Windows 10/11 IoT Enterprise, Linux
Inquire About This Product
basic information
Specifications ■CPU Intel Atom x7433RE / x7835RE ■Chipset SoC ■Memory 1 x DDR5-4800, up to 16GB ■Storage 1 x 2.5” SATA 6Gb/s HDD/SSD bay ■Expansion Slots: M.2 2280 M-Key ×1: PCIe Gen3 ×2 M.2 2230 E-Key ×1: PCIe Gen3 ×1 / USB 2.0 M.2 3042/3052 B-Key ×1: PCIe Gen3 ×1 / USB 2.0 SIM Card Slot ×1: for M.2 B-Key ■I/O Connectors 2.5GbE ×2 (M12 X-Code), Fiber Optic LAN 1 x 1GbE (optional), 1 x USB 3.2 Gen1, 2 x USB 2.0, 2 x RS232/422/485, 2 x HDMI (3840x2160), 2 x CANBUS, 4 x DI, 4 x DO ■Input Power DC 10–28V ■Operating Temperature -40°C ~ 70°C (with SSD) ■Weight 2.58kg
Price information
Open price
Delivery Time
Applications/Examples of results
Factory and Building Automation / Multimedia Systems / Digital Signage
Line up（2）
| Model number | overview |
|---|---|
| SWBOX-ASL-R3C-R10 | Rugged Fanless Stainless System (IP69K) w/ Intel Atom x7433RE, 8GB DDR5, M12 I/O, Dual 2.5GbE, RS-232/422/485, CAN, GPIO, 10-28V DC |
| SWBOX-ASL-R4C-R10 | Rugged Fanless Stainless System (IP69K) w/ Intel Atom x7835RE, 8GB DDR5, M12 I/O, Dual 2.5GbE, RS-232/422/485, CAN, GPIO, 10–28V DC |
