IEI, equipped with AMD Ryzen 7000/8000 series mobile processors, operating temperature -20 to 60°C, fanless operation.
【IEI TANK-8700-MPHX Features】 ■ Width 254.4 × Height 127.2 × Depth 205 mm ■ Equipped with AMD Ryzen 7000/8000 series mobile processors, fanless ■ Options available for Ryzen 5 8645HS / Ryzen 7 8845HS / Ryzen 9 8945HS ■ Supports up to 96GB DDR5-5600 SO-DIMM memory ■ Silent operation and long-term continuous operation due to fanless design ■ Equipped with 2.5GbE LAN x2 ■ Equipped with USB 3.2 Gen2 x3, USB 2.0 x3 ■ Abundant serial interfaces with RS-422/485 x2, RS-232 x3 ■ Equipped with 4 input / 4 output digital I/O ■ Supports independent output for three screens via DP++, HDMI, USB4 ■ Equipped with M.2 x3 and PCIe expansion slots ■ 12–28V DC power input, ACC Mode supported ■ Supports remote management via IPMI ■ Operating temperature range of -20 to 60℃ ■ Compatible with Windows 10/11 IoT Enterprise, Linux ■ CE/FCC compliant
Inquire About This Product
basic information
Specifications ■CPU: Intel Atom x7433RE / x7835RE, Intel Processor N150 ■Chipset: SoC ■Memory: Up to 16GB, 2 x DDR5-4800MHz memory ■Storage: 2 x 2.5” SATA 6Gb/s HDD/SSD bay ■Expansion Slots: M.2 M-Key x1, M.2 A-Key x1, M.2 B-Key x1, PCIe Gen4 x8 x1, PCIe Gen3 x4 x1, PCIe Gen3 x1 x1 (3A SKU only), PCI x1 (3B SKU only) ■I/O Connectors: 2 x 2.5GbE, 1 x RJ45, 3 x USB 3.2 Gen2, 3 x USB 2.0, 1 x USB4, 2 x RS-422/485, 1 x HDMI, 1 x DP++ ■Input Power: DC 12–28V (DC jack/terminal block, ACC Mode compatible) ■Operating Temperature: -20–60℃ ■Weight: 1.13kg
Price information
Open price
Delivery Time
Applications/Examples of results
Factory and Building Automation / Multimedia Systems / Digital Signage
Line up（6）
| Model number | overview |
|---|---|
| TANK-8700-MPHX-89AD-3A-R10 | Ruggedized Fanless embedded system with AMD Ryzen 9 8945HS 4.0 GHz, (up to 5.2 GHz, 8 Core, TDP 45W), 16GB DDR5 pre-installed memory, PCIe x8/PCIe x4/PCIe x1, HDMI/DP/USB4, 12~28V DC, RoHS |
| TANK-8700-MPHX-89AD-3B-R10 | Ruggedized Fanless embedded system with AMD Ryzen 9 8945HS 4.0 GHz, (up to 5.2 GHz, 8 Core, TDP 45W), 16GB DDR5 pre-installed memory, PCIe x8/PCIe x4/PCI, HDMI/DP/USB4, 12~28V DC, RoHS |
| TANK-8700-MPHX-87AD-3A-R10 | Ruggedized Fanless embedded system with AMD Ryzen 7 8845HS 3.8 GHz, (up to 5.1 GHz, 8 Core, TDP 45W), 16GB DDR5 pre-installed memory, PCIe x8/PCIe x4/PCIe x1, HDMI/DP/USB4, 12~28V DC, RoHS |
| TANK-8700-MPHX-87AD-3B-R10 | Ruggedized Fanless embedded system with AMD Ryzen 7 8845HS 3.8 GHz, (up to 5.1 GHz, 8 Core, TDP 45W), 16GB DDR5 pre-installed memory, PCIe x8/PCIe x4/PCI, HDMI/DP/USB4, 12~28V DC, RoHS |
| TANK-8700-MPHX-85AD-3A-R10 | Ruggedized Fanless embedded system with AMD Ryzen 5 8645HS 4.3 GHz, (up to 5.0 GHz, 6 Core, TDP 45W), 16GB DDR5 pre-installed memory, PCIe x8/PCIe x4/PCIe x1, HDMI/DP/USB4, 12~28V DC, RoHS |
| TANK-8700-MPHX-85AD-3B-R10 | Ruggedized Fanless embedded system with AMD Ryzen 5 8645HS 4.3 GHz, (up to 5.0 GHz, 6 Core, TDP 45W), 16GB DDR5 pre-installed memory, PCIe x8/PCIe x4/PCI, HDMI/DP/USB4, 12~28V DC, RoHS |
