Transport up to 600 kg. With laser SLAM and rotation function, it can autonomously transport flexibly even in narrow passages.
The JX-600 is a rotating lift-type transport robot that supports the transportation of loads up to 600 kg using laser SLAM technology. It accommodates a minimum aisle width of 790 mm and positioning accuracy of ±5 mm, enabling high-precision autonomous transport even in limited spaces. Equipped with laser navigation sensors at the front and rear, it enhances obstacle detection and avoidance capabilities. The body features a rotation function, allowing for smooth direction changes in narrow aisles and between shelves, and it can flexibly adapt to layout changes. Despite its compact design, it supports transportation of up to 600 kg and can be used in a wide range of applications, including e-commerce logistics warehouses, parts transport, and manufacturing sites. It is equipped with a lifting platform to accommodate the pickup of various racks and transport items. ♦ Main Features - Maximum load capacity of 600 kg - Autonomous operation using laser SLAM technology - Minimum aisle width of 790 mm - Positioning accuracy of ±5 mm - Rotation function for easy maneuverability in tight spaces - Maximum travel speed of 1.5 m/s or less - Front and rear LiDAR equipped - Standard automatic charging function - Standard shelf recognition function - Standard Wi-Fi roaming function - Various optional features including high-precision positioning with QR codes
Inquire About This Product
basic information
Product Name: Laser SLAM Rotating Elevating Transport Robot Model: JX-600 Navigation Method: Laser SLAM Method Dimensions: 950 × 650 × 250mm Rotating Diameter: φ1015mm Body Weight: Approximately 170kg (including battery) Maximum Load Capacity: 600kg Minimum Ground Clearance: 25mm Elevating Platform Dimensions: 850 × 650mm Maximum Elevation Height: 60 ± 2mm Operating Environment Temperature: 0–50℃ Operating Environment Humidity: 10–90% RH (without condensation) Minimum Passage Width: 790mm Positioning Accuracy: ±5mm Posture Angle Accuracy: ±0.5° Maximum Travel Speed: 1.5m/s or less Battery: 48V/24Ah Lithium Iron Phosphate Continuous Operating Time: Approximately 8 hours Charging Time: 10% to 80% within 2 hours Charging Method: Manual charging / Automatic charging compatible
Price information
Price information: Consultation required. *Varies depending on specifications and options. Please contact us for details.
Delivery Time
※Delivery time: For standard machines, approximately 3 months after order placement. *Delivery time may vary depending on specifications and production status.
Applications/Examples of results
Transportation of racks and carts in logistics warehouses Transportation of parts between manufacturing lines Automated transportation in e-commerce logistics centers Transportation between processes within factories Unmanned transportation of heavy goods Labor-saving and automation using AGVs and AMRs
