If we could help with DUCO's affordable and high-performance collaborative robots...
★★A True Pioneer Forged in the Fierce Chinese Market★★ —DUCO's "Five Firsts in China," Inheriting the DNA of the Prestigious 'Shenyang Xinsong'— The world's most challenging market, the Chinese market, which accounts for 50% of the robot market. Emerging victorious from this fierce competition, the collaborative robot that continues to expand the possibilities of automation is "DUCO (Zhongke Xinsong)." Independently developed from the industrial robot giant Shenyang Xinsong, DUCO has consistently led the market with its overwhelming development capabilities. Innovative technologies that are "first in China" and unmatched by competitors will solve the challenges in your workplace. ■ Five Major Innovations Unique to DUCO that Revolutionize the Workplace ★Numerous Firsts in China★ - 7-axis collaboration: Flexible like a human arm, adaptable to narrow spaces - Dual-arm collaboration: Reproducing two-handed tasks, achieving advanced and precise assembly - 25kg heavy load: Strongly supporting heavy labor such as palletizing - 2m long arm extension: Covering a wide range of tasks with a single unit - Mobile (composite type): Automating transportation with autonomous driving and robotic arms Are you ready to break through the limits of productivity with proven performance recognized by the market?
Inquire About This Product
basic information
Main specifications of DUCO's multi-purpose 6-axis collaborative robot "GCR Series" Model Name Payload Reach Repeatability GCR3-618 3kg 618mm ±0.02mm GCR5-910 5kg 917mm ±0.02mm GCR7-910 7kg 917mm ±0.02mm GCR10-1300 10kg 1300mm ±0.03mm GCR12-1300 12kg 1300mm ±0.03mm GCR16-960 16kg 960mm ±0.03mm GCR16-2000 16kg 2000mm ±0.05mm GCR20-1400 20kg 1400mm ±0.05mm GCR25-1800 25kg 1800mm ±0.05mm GCR30-1100 30kg 1100mm ±0.05mm Common basic specifications Degrees of freedom (number of axes): 6 axes Protection rating: IP54 / IP65 Maximum TCP speed: up to 3.5 to 3.8 m/s (depending on the model) Safety features: Equipped with 16 TÜV-certified safety functions Installation orientation: All directions (supports ceiling and wall mounting)
Price information
Negotiable
Price range
P5
Delivery Time
P4
※We will arrange according to the quantity and your requests. Please feel free to consult with us.
Applications/Examples of results
DUCO, honed in the harsh Chinese market, is adopted in a wide range of fields from manufacturing and logistics to precision machinery, contributing to automation and labor reduction. 【Main Applications and Automation Scenarios】 - Welding and Cutting: Automating high-quality welding of automotive parts and sheet metal processing with high-precision trajectory control. - Palletizing: A 25kg heavy load, 2m long-arm model takes over heavy labor in logistics warehouses. - Pick and Place: Mobile (AMR composite) robots automate parts transportation and picking between processes. - Screw Tightening and Assembly: Dual-arm models and high-precision sensors enable precise assembly and inspection of electronic devices. - Machine Tending: Automating workpiece loading and unloading for machine tools 24/7 to maximize operational efficiency. 【Proven Track Record】 There are numerous operational achievements primarily in advanced factories of global leaders in automotive, semiconductors, electronic components, 3C (home appliances), medical devices, and chemicals.
Company information
Meisei Corporation is a general trading company that sells a wide variety of products overseas, ranging from large equipment and welfare supplies to miscellaneous goods, as well as providing technical guidance, human resource introduction, and real estate services abroad. Although the growth of the Chinese economy has slowed, it still maintains a higher growth rate compared to Japan. The investment appetite remains strong, and there is significant demand for Japanese machinery and equipment. This is where our company's significance lies, and we are committed to serving as a bridge between Japan and China, continuing to exert our efforts and contribute to the development of both countries.
