No need for a high budget for safety measures! Woodworking sliding saw equipped with non-contact PCS.
K700 PCS
The advanced non-contact safety device "PCS" can now be installed on standard machines. The investment in safety for professional-grade sliding saws is now achievable at a realistic price.
■Do you have such challenges? "I want to introduce highly safe machinery, but I can't afford the expensive top models." "I want to implement safety measures to protect employees from accidents within a limited equipment investment budget." ■Investing in safety at a realistic price range The non-contact safety device "PCS," which could only be installed on high-priced machines until now, is now available for standard machines. The saw blade itself acts as a sensor, detecting the approach of a human body or other objects before contact. The blade retracts below the table in milliseconds, preventing cutting accidents. ■No damage to the machine & minimal burden on operations The electrical detection system, which does not use cameras, is unaffected by dust and operates stably. Even if it does activate, it does not damage the machine or blade, allowing for quick resumption of work with simple operations. ■Applications and product configuration - Strengthening safety measures in woodworking factories, furniture and fixture manufacturing, and various educational settings. - A wide range of models from space-saving 1300mm specifications to large material-compatible models. There is no need to give up on safety measures due to budget constraints. For detailed product specifications, live demonstrations, or to download the catalog, please feel free to contact us.
Inquire About This Product
basic information
【Basic Specifications】 ■ Blade diameter: Maximum 315mm (Maximum cutting height 104mm at 90°) ■ Blade tilt angle: 90° to 45° ■ Rotational speed: 4,800rpm ■ Motor output: 3.0kW (4.0HP) / 4.0kW / 5.5kW / 7.3kW ■ Sliding table cutting length: 1,300mm / 1,550mm / 2,050mm / 2,500mm / 2,800mm / 3,200mm / 3,700mm ■ Various options: Electric lift and angle adjustment (Power Drive), electric bevel (120mm), Dado cutter (supports maximum width of 19.5mm), outrigger table, digital dimension display, angle guide with length correction function.
Price range
Delivery Time
Applications/Examples of results
■High-precision cutting processing at woodworking and furniture manufacturing factories ■Safety measures and on-site training for young and inexperienced workers ■Various educational settings, including schools and vocational training facilities *For more details, please contact us.*
catalog（1）
Download All Catalogs
Company information
Our company is a business that provides total support for future woodworking processing technologies. We mainly handle products such as "HOLZHER," which offers edge banders, CNC machines, and running saws, as well as "FELDER," which includes sliding saws, vertical axis machines, and hand planers. Please feel free to contact us if you have any inquiries.
