Film Capacitor Catalog

Compact and lightweight! Features capacitors with a laminated structure using metallized PPS film.

This catalog introduces the film capacitors manufactured by Panasonic, handled by Chiyoda Electronic Equipment Co., Ltd. It includes a variety of products such as the chip-type multilayer metallized PPS film capacitors "ECHU(X) series" and "ECHU(C) series," as well as the chip-type multilayer metallized PEN film capacitors "ECWU(X) series" and "ECWU(C) series." Please use this for selecting products. [Contents (excerpt)] ■ Product system table ■ Major industries (sets) and main product types ■ AC voltage ratings for DC rated voltage products ■ Taping specifications for automatic mounting ■ Temperature characteristics and frequency characteristics *For more details, please refer to the PDF document or feel free to contact us.
