A simple and powerful security system! Prevents theft with duplicated keys.
It is a simple yet powerful security system that protects important vehicles and construction machinery from unauthorized engine starts. Once security is activated, the engine will not start even if duplicate keys, direct wiring, or an immobilizer cutter are used. ■ Compatible with 12V to 24V! It can be easily installed on a wide range of vehicles and heavy machinery, from ordinary cars to trucks, dump trucks, cranes, agricultural machinery, construction equipment, and rental vehicles. It is a trusted product with over 10 years of extensive delivery experience. ■ Zero battery burden & excellent cost-effectiveness Since there is no standby current, it does not put any load on the battery even if the vehicle is not used for a long time. The running cost is very economical, consisting only of the remote control battery cost, which is about once a year. ■ Easy operation with just one button After the engine is turned off, security is automatically activated immediately. Deactivation is as simple as pressing a button on the dedicated remote key. There is no concern about malfunction due to radio interference, and the compact main unit can be installed anywhere inside the vehicle. *For more details, please feel free to contact us. https://www.joqr-bkc.co.jp/contact_media.php
Inquire About This Product
basic information
【Basic Specifications】 Compatible Power Supply: DC12V to 24V (suitable for regular cars, trucks, various construction machinery, agricultural machinery, etc.) Operating Environment: -30 to 80 degrees (excellent heat resistance suitable for extremely cold areas to hot car interiors) 【Main Unit】 Dimensions: 92×58×18mm (compact size that can be hidden in inconspicuous places in the car) Current Consumption: 12mA (during operation) *No standby current, so there is no burden on the battery 【Remote Key (2 included)】 Dimensions: 56×36×13mm Battery Used: DC3V (CR2032 × 1) Current Consumption: 0.044mA (very economical with battery replacement only about once a year) 【Functions and Options】 Smart Key Registration: Up to 10 remote keys can be registered Options: Anti-theft device installation sticker, master key production 【Installation Precautions】 If the relay is for a 24V vehicle with a current value of 15A or more, relay modification is necessary. For the ignition system current value when the key is ON, it is recommended to be 10A or less, and about 3 to 5A or less for 24V heavy machinery. Due to the precision components, please consider the effects of vibration, water, and heat during installation.
Price information
For more details, please feel free to contact us using the "Contact Us About This Product" button. Alternatively, you can contact us here: https://www.joqr-bkc.co.jp/contact_media.php
Price range
P3
Delivery Time
Applications/Examples of results
"For the prevention of theft of all vehicles and construction machinery" TORALES is a security system designed to protect valuable assets, such as vehicles, from theft groups and unauthorized removal. It neutralizes all methods of illegal ignition, including key duplication, direct wiring, and immobilizer cutters. ■ Main compatible vehicle types and installation scenes It supports power supplies from DC12V to 24V, allowing for a wide range of installations across various vehicle types, from passenger cars to large construction machinery. ◇ Construction machinery and heavy equipment: Hydraulic excavators, mini excavators, and various construction machines (with numerous achievements in construction machine manufacturers and rental companies) ◇ Commercial vehicles and trucks: Trucks, dump trucks, unic cranes, and vehicles owned by logistics and transportation companies ◇ Agricultural machinery: Tractors, combines, and other agricultural machines that are often stored outdoors ◇ General vehicles and business cars: Private cars, leased vehicles, and display/inventory vehicles at used car dealerships Construction machinery and commercial vehicles, which are often stored for long periods in locations out of sight, are constantly exposed to the risk of theft. This product has zero standby current, so there is no worry about draining the battery of vehicles that are not used for extended periods, allowing for peace of mind in security measures.
