No cables needed to display on your smartphone! The waterproof feature is IP69K certified.
This is a high-performance backup camera that can be installed at the rear of the vehicle and allows you to check real-time video on your smartphone (compatible with Android/iOS). By simply connecting to the dedicated app "Vehicle Viewer" via Wi-Fi, you can easily monitor the rear view. Equipped with a high-resolution CMOS sensor, it provides clear images and features infrared night vision with a distance of 8 to 10 meters, a wide-angle design with a field of view of over 110°, and the highest level of IP69K waterproof rating, ensuring excellent basic performance that can be safely used at night or in bad weather. There are two power models available to choose from based on your needs. Constant power model (QRC-C873DW): By connecting the included power supply cable, it allows for stable continuous power supply and reliable operation. Battery-powered model (QRC-C897DW): A wireless structure that can be easily attached and detached with a strong magnet. It achieves approximately 11 to 12 hours of continuous discharge during the day on a single charge, with a maximum battery standby time of 90 days. Additionally, the app offers features such as parking line display, saving still images and videos, switching between image quality (HD/SD), and safety designs like overcharge and over-discharge protection.
Inquire About This Product
basic information
【Common Basic Specifications】 Image Sensor: 1/3 inch (or 1/2.9 inch) CMOS IMX224 Effective Pixel Count: 1280(H)×720(V) to 1920(H)×1080(V) Field of View / Night Vision Distance: 110° to 120° / 8 to 10m (Infrared night vision compatible) Wireless Specifications: 2.4GHz and 5.1GHz bands, IEEE 802.11a/b/g/n/ac Transmission Distance / Delay Time: 50 to 60m / 200ms Waterproof Rating: Highest level IP69K certified Supported OS / Audio: Android, iOS / Built-in microphone Operating and Storage Temperature: -20℃ to 60℃ 【Model-Specific Specifications】 ◆ Constant Power Model (QRC-C873DW) Power Supply Method: Constant power (using the included power supply cable) ◆ Battery-Integrated Model (QRC-C897DW) Battery Capacity: 3.6V / 6400 to 6700mAh Discharge Time: Approximately 11 to 12 hours during the day / Approximately 5 hours at night Charging Time / Voltage: 5V/8 hours, 12V/3 to 3.5 hours / DC 5 to 12V Dimensions / Weight: 116×80×66mm / 650g (main unit) Installation Features: Detachable structure with a powerful magnet
Price information
For more details, please feel free to contact us using the "Contact Us About This Product" button. You can also reach out to us from here: https://www.joqr-bkc.co.jp/contact_media.php
Price range
P2
Delivery Time
Applications/Examples of results
◆ Blind Spot Assistance for Large and Special Vehicles The rear of trucks, buses, camper vans, and construction machinery has many blind spots, increasing the risk of contact accidents while reversing. By installing this product at the rear, safe rear visibility can be achieved from a smartphone. ◆ Difficult-to-Wire Vehicles and Temporary Use (Battery-Powered Model) The QRC-C897DW is equipped with a powerful magnet and built-in battery, making it ideal for use on the rear of trailers where wiring is extremely difficult, or for vehicles that need to be temporarily installed only when necessary. ◆ Work Monitoring and Safety Assurance in Harsh Environments With an IP69K waterproof rating, it can be used without concern for failure in dusty construction sites, outdoors during rain or snowfall, or on vehicles undergoing high-pressure hot water cleaning. ◆ Support for Reversing and Parking in Nighttime or Dark Areas Equipped with infrared night vision and a microphone, it allows for accurate awareness of the rear situation through both video and surrounding sounds, even on dark roads or inside warehouses at night. With an angle adjustment of up to 87 degrees, optimal visibility for each vehicle can be ensured.
catalog（1）
Download All Catalogs
Company information
Our company, as a subsidiary of Bunka Hoso, continues to create various businesses centered around broadcasting-related activities. We offer a shopping service that allows you to enjoy purchasing special member products and receiving newsletters with great deals, as well as event planning and management, including concerts and promotions, to meet various requests related to events. Please feel free to contact us with any inquiries.
