Wireless camera for trucks, buses, and construction machinery.
Battery-powered wireless camera QRC-C897D
Eliminate the visibility issues during the reverse and left-turn maneuvers of each vehicle! Prevent contact accidents and entrapment incidents.
Introducing the "Battery-Powered Wireless Camera QRC-C897D," which is easy to install without wiring. It has already obtained approval for Japanese radio wave regulations, allowing you to use it immediately after installation. This product employs a simple magnetic mounting method with a powerful magnet, making it ideal for installation on complex vehicles where mounting is difficult, as well as for use as a simple surveillance camera. 【Main Features】 ◇ Excellent Basic Performance: High-quality Full HD (1920×1080), a wide-angle lens of 130°, and it also includes a microphone. ◇ Adaptable to Darkness and Harsh Environments: Infrared LEDs (effective range of 8 to 10 meters) provide clear images even at night, and it meets the highest waterproof standard "IP69K" and can operate in a wide temperature range of -20 to +60°C. ◇ Reliable Long Battery Life: Equipped with a large 6400mAh battery, it can operate continuously for about 12 hours during the day and about 5.5 hours at night. The LED indicator next to the switch allows you to easily check the remaining battery level. It also includes safety features such as overcharge, over-discharge, and short-circuit protection. It strongly supports safety and monitoring on-site without the hassle of complicated wiring. For more details, please refer to the documentation or feel free to contact us.
Inquire About This Product
basic information
◆Power and Battery: It has a built-in 3.6V/6400mAh battery, supporting continuous operation for about 12 hours during the day and about 5.5 hours at night. The charging time is approximately 8 hours at 5V and about 3 hours at 12V (at 25°C). ◆Camera Performance: It features a 1/2.9-inch CMOS image sensor, boasting effective pixels of 1920×1080 (Full HD) and a wide angle of 130°. ◆Night and Audio: With a minimum illumination of 0Lux and infrared LEDs (effective range of 8 to 10m), it enables night shooting and is equipped with an audio microphone. ◆Wireless and Transmission: It operates in the frequency range of 2401MHz to 2483.5MHz, using DSSS spread spectrum technology, with a transmission distance of 100m and a delay of 200ms. ◆Durability and Environment: It complies with the highest waterproof standard "IP69K" and can withstand harsh environments with an operating and storage temperature range of -20 to +60°C. ◆Others: The dimensions are 116×80×66mm, and it weighs 670g. It includes a powerful magnet, an LED battery level indicator, and various protection features (overcharge, over-discharge, short circuit, etc.).
Price information
A dedicated monitor is also required for use. We offer sizes of 7 inches and 10.1 inches, and we also have waterproof options available. *For more details, please feel free to contact us via the "Inquiries about this product" button. You can also contact us here: https://www.joqr-bkc.co.jp/contact_media.php
Price range
P2
Delivery Time
※The delivery time will vary depending on the quantity.
Applications/Examples of results
The "QRC-C897D" is a camera that features a wireless design that eliminates the need for wiring, a powerful magnetic mounting method, and high environmental resistance. It can be utilized in a wide range of scenarios, as outlined below. ◇ Checking blind spots and rear views of special vehicles and construction machinery: It can be easily installed without the need for cable wiring on complex mounting areas of heavy machinery, trucks, agricultural machinery, and forklifts, thanks to its powerful magnets. ◇ Simple surveillance camera for construction sites and factories: With a transmission distance of 100 meters and infrared LEDs (8-10 meters) that ensure safety even at night, it is ideal for security and monitoring in outdoor work sites and warehouses where securing power is difficult. ◇ Operation in harsh environments: Compliant with the highest waterproof standard "IP69K" and with a wide operating temperature range of -20 to +60°C, it is suitable for installation on vehicles that operate in outdoor sites affected by weather or undergo high-pressure hot water cleaning. ◇ Understanding the situation on-site, including audio: Equipped with an audio microphone, it is useful for site management that requires simultaneous confirmation of surrounding sounds and instructions, in addition to video. As a portable monitoring and verification solution that can be installed anywhere, it supports the safety and efficiency of operations.
