With four cameras and AI eyes, gently watching over safety during work. The reliable partner for forklifts, "BFV202."
In environments where forklifts are used, unexpected collisions and entrapments still occur, making safety measures essential. The "BFV202" monitors the surroundings with four cameras installed at the front and rear, and AI automatically detects workers who enter designated caution and danger areas. When detection occurs, it issues audio and visual warnings to the driver, helping to raise awareness of potential hazards and preventing serious accidents such as entrapments and collisions. Compared to a system that relies solely on visual checks, the BFV202 enables more reliable and sustainable safety management. It can be retrofitted to existing forklifts, eliminating the need for vehicle replacement or extensive construction. We have provided a video that clearly illustrates the usage of this system on-site! Please take a look.
Inquire About This Product
basic information
**Function** Detection Target: Pedestrians (approximately 12m) Detection Range: The detection range can be set arbitrarily Front and rear of the forklift 0.5m to 12m Detection Area: 2 areas (Danger Area / Detection Area) **Identification Unit** Power Supply (Power Consumption): DC9–16V (Standard) DC9–72V (Optional) / 6W–7W Camera Input: NTSC: 4ch (Switchable between 2ch forward and 2ch rear based on direction) Mounting Angle: -35° to -55° Monitor Output: NTSC: 1ch Dimensions: 156 (W) × 48 (H) × 112 (D) mm (excluding protrusions) Temperature (Operating): -30 to +60℃ (Storage): 30 to +80℃ **Camera** Type: NTSC / CMOS Dimensions: 23 (W) × 23 (H) × 32.6 (D) mm / Approximately 54g Temperature: -20 to +70℃ **Monitor** Warning Display: Highlights the detected subject with a red frame and orange color Dimensions / Weight: 181 (W) × 134 (H) × 28 (D) mm / 860g (Monitor body) Operating Ambient Temperature: -10°C to 60°C **Speaker** Dimensions / Weight: Diameter φ152mm × Total Length 178mm / 1.2kg Operating Temperature Range: -20℃ to +55℃
Price range
Delivery Time
Applications/Examples of results
【Purpose】 - Prevention of contact and entrapment accidents during forklift operation and loading/unloading tasks - Assistance with the driver's blind spots and support for visual confirmation - Utilization as a tool for safety education and improvement of the work environment
