Collecting and analyzing temperature data for each mold. This is a temperature measurement system that can be used for process improvement and reducing defective products.
Responding to the need to "improve quality by utilizing process data." 'MiEL Thermo HT' provides stable temperature data for each mold, which can be used for analysis and improvement. Features: - Process improvement utilizing data - Stabilization of quality and reduction of defects - Reduction of labor hours by decreasing the number of thermocouple operations - Easy implementation into existing furnaces If you are considering data-driven quality management, please download the materials for more details or feel free to contact us.
Inquire About This Product
basic information
【Standard Specification Example】 ● Equipment Configuration ・Complete set of optical devices ・Complete set of other hardware (such as PC) ・Temperature analysis software ● System Details (1) Measurement Temperature Range: 600℃ to 1600℃ (recommended above 1000℃) (2) Measurement Area: 235mm×310mm (at a distance of 2.5m to the measurement target; varies with distance) (3) Measurement Mode: Line measurement, area measurement *Both modes are equipped with automatic molten metal recognition function (4) Input: Camera…Power supply via PC connection, PC…100V power supply (5) Output: Instantaneous value, peak hold, moving average, average value per mold Data is saved in CSV format on the PC (6) Operating Temperature: 0℃ to 50℃ *Cooling mechanism via air purge is recommended for the camera; options for camera box are also available (7) External Integration: Communication integration via Ethernet/IP
Price information
Please feel free to contact us.
Delivery Time
Applications/Examples of results
Pouring process in cast iron casting
