Reduce electricity costs without replacing the freezer!
Riduck is an energy-saving device that can be retrofitted to improve the mechanical efficiency of commercial refrigeration and air conditioning units. By simply installing it on existing equipment, it reduces the compressor load and lowers power consumption. This allows for energy savings and CO₂ reduction while keeping equipment renewal costs down. 【Features】 ■ Can be retrofitted to existing equipment (no renewal necessary) ■ Improves mechanical efficiency of refrigeration and air conditioning units ■ Reduces electricity costs through lower power consumption ■ Extends equipment lifespan by reducing load ■ Contributes to CO₂ emission reduction 【For customers like these】 - Want to reduce electricity costs for refrigeration in the food manufacturing industry - Want to consider improvement measures before equipment renewal - Want to suppress demand increases - Concerned about increased load and aging of refrigeration units
Inquire About This Product
Related Videos
basic information
【Purpose】 Energy-saving device for commercial refrigeration and air conditioning equipment (Equipment using compressors and refrigerants) 【Applicable Models】 - Screw-type refrigeration units - Reciprocating refrigeration units - Scroll-type refrigeration units - Package air conditioners - Chiller units 【Electrical Specifications】 Power supply: AC100V / AC200V (50/60Hz) Power consumption: 1W Output voltage: 40mV Application method: Non-contact application from outside the refrigerant piping EMC test compliant 【Mechanical Specifications】 Main body dimensions: W134×D60×H23mm Weight: 130g Exterior: ABS resin Installation method: Installed inside wall boxes, etc. Piping connection: Fixed externally to refrigerant copper pipes (non-invasive) 【Operating Environment】 Operating temperature range: -20℃ to 60℃ Operating humidity range: 85% RH or less (no condensation)
Price information
【Estimated Introduction Costs】 ■ Small to medium-sized refrigeration units (up to 50 kW class) Approximately 800,000 to 1,200,000 yen ■ Medium-sized refrigeration units (50 to 150 kW) Approximately 1,200,000 to 1,800,000 yen ■ Large refrigeration units (over 150 kW) Approximately 1,800,000 to 2,500,000 yen In the case of a power reduction rate of 10-15%, the investment recovery period is estimated to be about 2 to 4 years. (This may vary depending on electricity rates and operating hours) 【Guidelines for Consideration of Introduction】 - Companies with refrigeration equipment that has annual electricity costs of over 5 million yen - Companies considering improvement measures before equipment renewal
Price range
P3
Delivery Time
P4
※About 2 to 3 weeks.
Applications/Examples of results
【Food Manufacturing Industry】 ■ Frozen Food Factory (Screw Freezer) Purpose of Introduction: Measures against rising electricity costs → Reduction of compressor load, reduction of electricity consumption ■ Meat Processing Plant (Reciprocating Freezer) Purpose of Introduction: Efficiency improvement of aging equipment → Adopted as a measure to extend the life of equipment before replacement ■ Confectionery Factory (Packaged Air Conditioning + Chiller) Purpose of Introduction: Suppression of summer peak electricity demand → Demand reduction measures 【Logistics and Storage Facilities】 ■ Refrigerated Warehouse Purpose of Introduction: Reduction of electricity for 24-hour operating equipment → Compression of running costs 【Distribution and Retail】 ■ Supermarket Purpose of Introduction: Reduction of electricity for showcase and backroom freezers → Energy-saving measures for the entire store 【General Manufacturing Industry】 ■ Metal Processing Factory (Factory Air Conditioning) Purpose of Introduction: Reduction of electricity for air conditioning equipment → Introduced as an improvement measure before equipment renewal
Detailed information
-
We will check the model, year of manufacture, refrigerant type, refrigerant charge, operating hours, set temperature, and actual temperature of the refrigeration and air conditioning equipment during the on-site inspection.
-
We will continuously measure the current at 5-minute intervals before and after installing the Reduck. By comparing power consumption under the same conditions, such as outdoor temperature, we will objectively evaluate the improvement in efficiency.
-
The signal wire from the Reduck is wrapped around the refrigerant piping and secured with aluminum tape. It then acts on the refrigerant flowing through the system.
-
The current data collected at 5-minute intervals were plotted against outdoor temperature, and regression analysis was used to compare power consumption under the same temperature conditions. After installing the Reduck, a decreasing trend in current values was observed across all temperature ranges.
-
Based on the results of the reduction analysis, we will report the estimated annual cost savings and the payback period, and then proceed with the permanent installation work. Note: This analysis is a comparative evaluation based on measured data correlated with outdoor temperature. However, since it is difficult to completely standardize production conditions and operating parameters, the calculated reduction rate and cost savings are provided for reference only and do not guarantee future savings.
