Electric forklifts for [lift conveyors (vertical conveyors)] become emergency power sources!
Three-phase 200V (9.9kVA) inverter: iGen.10000LF
【BCP Measures】Electric forklifts as emergency power sources! How to implement BCP measures for lift conveyors at low cost.
During power outages caused by typhoons or earthquakes, the "vertical conveyor (Rifcon)" responsible for transporting goods between floors comes to a complete standstill, paralyzing logistics. However, the reality is that the introduction of expensive emergency generators poses a high cost barrier. That’s why we recommend the high-output three-phase 200V inverter "iGen.10000LF." By simply connecting it to the battery of the electric forklift on-site, it quickly transforms into an emergency power source to operate the Rifcon. This allows you to leverage existing assets and achieve reliable BCP measures at a low cost. [Three Reasons to Choose This Product] 1. Overwhelmingly Low Cost Significantly reduces investment compared to the installation and maintenance costs of generators. 2. 10kW High Power Effectively drives the three-phase 200V motor of the Rifcon, which cannot be operated by standard portable power sources. 3. Excellent Mobility Since it can be moved along with the forklift, it can flexibly supply power to necessary equipment during power outages, such as shutters and lighting. If you want to know whether your Rifcon can operate or if you would like to see the specifications, please download the materials for confirmation.
Inquire About This Product
basic information
[Specifications] Output Voltage: Three-phase (power) 200V Input Voltage: DC48V Rated Output: 9.9kVA Maximum Output: 12kVA Output Frequency: 50/60Hz Output Waveform: Sine wave Circuit Method: P.W.M method microcontroller control Protection Circuit: Output overload protection, output short-circuit protection circuit, high-temperature protection circuit Operating Environment Temperature: 0 to 40℃ Dimensions: 720mm x 625mm x 1,040mm Weight: 130kg *Specifications are subject to change without notice *For more details, please contact us
Price range
Delivery Time
Applications/Examples of results
■Usage examples: Automated warehouses, cargo elevators, drainage pumps, commercial freezers, etc. ★Compatibility confirmation and live demonstrations are currently available. Please refer to the catalog for details.
catalog（1）
Download All Catalogs
Company information
Daishin Co., Ltd. has been engaged in the business of power source-equipped machinery such as generators, pumps, and management machines for over 50 years since its founding. Among these, our uniquely developed inverter brand "iGen." has obtained various patents and utilizes the technology cultivated in the development of large inverter generators. It is combined with solar power generation, storage batteries, and V2H systems to effectively utilize renewable energy and is introduced as a measure for disaster prevention and business continuity planning (BCP). Daishin contributes to the effective use of renewable energy, BCP measures, and disaster recovery with its uniquely developed inverter technology, supporting people's lifelines.
