[Municipal Disaster Prevention] Instantly secure three-phase 200V from a single-phase power supply vehicle! Three-phase converter.
Single-phase - Three-phase converter: iGen.10000PT
[Disaster Prevention for Local Governments] Instantly secure three-phase 200V from a single-phase 200V power supply vehicle! The three-phase converter "iGen.10000PT," which has also been adopted by the Chubu Regional Police Bureau.
Ensuring "communication" is the top priority for maintaining regional infrastructure during disasters. However, while many municipalities possess mobile power supply vehicles that primarily output "single-phase 200V," critical equipment such as disaster prevention administrative wireless base stations require "three-phase 200V (power)," leading to a mismatch in power supply. The solution to this issue is the three-phase converter "iGen.10000PT," which has also been introduced by the Chubu Regional Police Bureau. This product instantly generates high-quality and stable three-phase 200V power from existing single-phase 200V sources. 【Benefits of Introduction】 1. Existing power supply vehicles can be effectively utilized without the need to purchase expensive three-phase compatible vehicles, contributing to significant cost savings. 2. Its compact design offers excellent mobility, making it easy to transport to disaster sites or load onto power supply vehicles. 3. It is effective not only for wireless base stations but also as a backup for large air conditioning units and water supply and drainage pumps in evacuation centers. For disaster prevention and crisis management officials who have "municipal power supply vehicles but are concerned about driving three-phase equipment," please consider this as a reliable BCP measure that leverages existing resources. Feel free to download the product catalog or consult us regarding specifications.
Inquire About This Product
basic information
■ Input Voltage: Single-phase three-wire AC 200V ■ Output Voltage: Three-phase AC 200V ■ Maximum Output: 12000VA ■ Rated Output: 9900VA ■ Output Frequency: 50/60Hz ■ Output Waveform: Sine Wave ■ Circuit Method: P.W.M Method Microcontroller Control ■ Protection Circuit: Output Overload Protection, Output Short Circuit Protection ■ Operating Ambient Temperature: 0 to 40℃ ■ External Dimensions: W575mm × D785mm × H745mm ■ Weight: 85kg
Price range
Delivery Time
Applications/Examples of results
[Usage Examples] There are proven applications for the following uses as an emergency power supply: ■ Wireless base stations ■ Commercial refrigerators ■ Elevators ■ Wells and water pumps * For more details, please feel free to contact us.
