We will introduce examples where design efficiency has significantly improved compared to the method of trial and error in design!
This is a case study introducing the use of "Presscale" to check the contact area of disc brake pads. In automotive disc brakes, braking is achieved through the friction between the disc and the brake pads. If the contact between the disc and the brake pads is not appropriate, issues such as poor braking performance, uneven pad wear, brake noise, and vibrations can occur. Data on phenomena such as braking performance, uneven pad wear, brake noise, and vibrations during braking are accumulated alongside the color change state of the Presscale. This allows for brake design to be conducted efficiently and appropriately in a short period. Additionally, the stability of quality can be confirmed with Presscale even after long-duration driving tests. [Case Overview] - Measurement Target: Brake Pads (Disc Brake) - Purpose: To check the contact area of disc brake pads - Results: Time reduction, material loss reduction - Challenge: The contact between the disc and brake pads is crucial for performance, safety, and component lifespan, but there has been no means to verify it until now. *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
【Introduction Effects】 ■Time Loss Effect: Significantly improves design efficiency compared to the trial-and-error method in design. ■Quality Loss Effect: Allows for easy measurement at any time, ensuring a stable braking system. The performance and stability of related components can also be improved. *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
catalog（1）
Download All Catalogs![[Case Study of Pressure Measurement Film] Brake Pads (Disc Brake)](https://image.mono.ipros.com/public/catalog/image/2117259/IPROS6244708904457533884.jpeg?w=120&h=170)
Company information
Our Measurement Film Solutions Division offers a variety of products, including high-temperature press scales and UV scales. We have the film "Press Scale," which allows for easy confirmation of invisible pressure and pressure distribution, and the revolutionary thermal distribution visualization film "Thermo Scale," which enables simple judgment of thermal distribution through color changes. Additionally, we provide a wide range of excellent inspection and measurement products that enhance precision, efficiency, and stability in manufacturing, inspection, and testing processes, all developed from the production processes of Fujifilm products.
