Quickly verify the accuracy of measuring instruments and machine tools on-site! High-precision artifacts compliant with international standards.
[Artifact for Accuracy Verification of Measurement and Processing Systems] This is a high-precision artifact (reference standard) designed to quickly and accurately verify and evaluate the "current measurement accuracy" of three-dimensional measuring machines (CMM) and machine tools on-site. Environmental changes in manufacturing settings, such as temperature fluctuations, vibrations, and aging, significantly impact measurement accuracy. This product utilizes a stable material with an extremely low thermal expansion coefficient, making it ideal for regular self-inspections and quick checks before processing. It enables reliable verification in accordance with international standards (such as ISO). By combining it with dedicated software "M3" and "M3MH," the verification process using the artifact can be automated. Without the need for complex setups, it can diagnose the geometric errors and calibration status of equipment in just a few minutes and automatically generate detailed verification reports. It optimizes the frequency of costly external calibrations while firmly establishing traceability of daily measurement quality. It reliably meets the demands of quality management and manufacturing sites that want to "maintain the reliability of measurement values at the highest level" and "prevent the occurrence of processing defects."
Inquire About This Product
basic information
This is a series of high-precision reference standards (artifacts) that are optimal for verifying and calibrating the accuracy of CMMs (coordinate measuring machines) and machine tools (on-machine measurement). Main materials: Ultra-low thermal expansion carbon fiber, ceramics, and high-stability alloys (minimizing the impact of temperature changes in the installation environment). Shape variations: A diverse lineup of geometric shapes tailored to evaluation items, including ball bars, tetrahedrons, and calibration spheres (reference balls). Compatible systems: CMMs from various manufacturers, as well as machining centers with 5-axis and 3-axis configurations. Compliance standards: Adhering to international metrology standards and traceability, including the ISO 10360 series. Main applications: Daily and regular accuracy checks, quick verification on machines before processing, and diagnosing measurement errors caused by environmental changes.
Price range
P5
Delivery Time
Applications/Examples of results
■ Main Uses - Daily and periodic accuracy checks: Voluntary regular accuracy inspections conducted in-house to complement the external calibration (once a year, etc.). - Diagnosis of the impact of environmental changes: Quantification of the effects of temperature changes and unexpected vibrations within the factory on the geometric accuracy of measuring instruments and machine tools. - Quick verification after collision incidents: Immediate confirmation of axis distortion and accuracy deviation when machine tools or CMMs collide (crash) with the workpiece. - Establishment of traceability for measurement and processing data: Improvement of the reliability of quality assurance data by using standard instruments compliant with international standards.
catalog（1）
Download All Catalogs
