Confirming the electric field strength generated by overhead power lines! Introducing simulation examples through frequency response analysis.
We will introduce a 2D electric field analysis assuming the section between transmission towers using our "PHOTO-VOLTjω." Above the power lines, there are two overhead ground wires. Below is the ground, which is also set to 0V. The analysis results are displayed as complex numbers. The analysis is conducted using the finite element method. 【Case Overview】 ■ Analysis Target: Power lines, ground, and surrounding space ■ Analysis Software Used: PHOTO-VOLTjω ■ Voltage Condition: Each conductor's voltage is 500kV/√3 ■ Analysis Type: 2D electric field analysis *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
basic information
【Other Case Overview】 ■ Perform frequency response analysis using finite element method electric field analysis software ■ Calculate electric field distribution from potential and charge distribution ■ Calculate dielectric loss and Joule loss ■ Calculate capacitance and electric force *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Applicable Fields】 ■ Fields where simulation of electric field and current distribution within conductors is required *For more details, please download the PDF or feel free to contact us.
catalog（3）
Download All Catalogs![[Analysis Case] Electric Field Analysis of Overhead Transmission Lines](https://image.mono.ipros.com/public/catalog/image/354241/IPROS16860307200099861233.jpeg?w=120&h=170)
Company information
At Photon, we are developing "electromagnetic field analysis software" that models and simulates products and components utilizing electromagnetic phenomena on a computer. In traditional design and development environments, the process has primarily revolved around trial and error through prototyping based on the experience of engineers and experiments with prototypes. However, conducting experiments using actual prototypes and analyzing the results requires significant time and cost. Moving forward, transitioning from an experimental and prototyping-based approach to an analysis-based design approach will be a crucial challenge for improving productivity, and establishing simulation technology as the core of analysis-based design techniques will be essential. In this context, Photon is developing and providing "analysis software" focusing on electromagnetic fields, as well as heat, vibration, and sound fields. By utilizing Photon's software, efficient development and design of various industrial products can be achieved. In this way, Photon aims to support users in reducing the number of prototypes, lowering development costs, and shortening development periods in their manufacturing environments, ultimately enhancing their competitiveness.
