High-capacity version of PAL-Plus current sensor for data centers
PAL-Plus Large Capacity Version | Hexacore Inc.
Proposal for integration into rack distribution boards and PDU panels. Added current monitoring for main and branch circuits.
When adding monitoring functions to rack distribution boards and PDU boards, it is important to consider compatibility with multiple circuits, internal space within the board, wiring labor, and integration with upper-level monitoring. The PAL-Plus large-capacity version is an AC current sensor that incorporates measurement and communication functions on the sensor side. Thanks to its connector and bus cable connection configuration, it can be installed in a monitoring setup for multiple points with reduced construction and labor, and it can be easily retrofitted to existing equipment (such as distribution boards). 【Usage Scenarios】 - Current monitoring of the main and branch circuits of rack distribution boards - Retrofitting current monitoring functions to the primary and secondary branch of PDU boards - Retrofitting to existing distribution boards 【Benefits of Implementation】 - Adding current monitoring functions to distribution boards contributes to enhancing proposal value - Incorporating measurement and communication functions on the sensor side allows for simple and low-construction retrofitting - The use of connectors and bus cables reduces the workload during installation - Modbus compatibility facilitates easy integration of current data with upper-level monitoring systems For more details, please download the materials and check them.
Inquire About This Product
basic information
【Main Specifications】 - Measurement Target: AC Current - Rated Current: 125A / 250A / 400A / 630A - Communication Method: Modbus RTU (RS-485) - Mounting Method: Split Clamp Type - When using PAL-Plus unit: Supports Modbus TCP integration and sensor power supply - Number of Connections: Up to 31 units per PAL-Plus unit Applicable cable diameter, mounting position, connection configuration, and required materials may vary depending on site conditions. For details, please refer to the PDF documentation.
Price information
Prices vary depending on specifications, quantity, and configuration. Please check the PDF materials and contact us, including the measurement locations and the number of target circuits.
Delivery Time
Applications/Examples of results
【Purpose】 - Adding current monitoring functionality to distribution boards for data centers and rack distribution boards - Proposal for integration into PDU boards and distribution boards with monitoring functions - On-site retrofitting of monitoring to existing distribution boards 【Examples of Use】 By adding current monitoring functionality to distribution board proposals, we can meet monitoring needs at the main, branch, and rack row levels. For more details, please refer to the PDF document.
