[Technical Seminar] Learning the Basic Characteristics of Electronic Components and SPICE with LTspice
Approximately 200 pages of text and about 30 LTspice circuit files are used, taking into account practical application after the course.
This seminar is a course to learn the basic characteristics of electronic components and how to effectively use LTspice. It quantitatively explains the basic characteristics of inductors (L), capacitors (C), and MOSFETs using formulas, and conducts transient analysis, AC analysis, and FFT analysis. It covers the frequency characteristics of L and C, the channel length, width, threshold, and temperature dependence of CMOS ICs, the use of voltage sources and current sources, as well as the compact, behavioral, S-parameter, and IBIS models of MOSFETs, the library creation of SPICE models, and how to utilize measures and raw files. *For more details, please check the related links or the seminar details in the catalog.*
Inquire About This Product
basic information
<Event Information> Format: In-person attendance / Live streaming (Zoom) Location: Japan IR Co., Ltd. Headquarters Seminar Room Date and Time: October 22, 2026 (Thursday) 10:00 AM - 5:00 PM Participation Fee: 49,500 yen (including tax) Instructor: Masashi Aoki
Price range
Delivery Time
Applications/Examples of results
<Seminar Program (Tentative)> Chapter 1: Seminar Overview Chapter 2: About SPICE Chapter 3: Obtaining and Installing LTspice Chapter 4: Let's Run LTspice Chapter 5: Inductors Chapter 6: Capacitors Chapter 7: Transmission Lines Chapter 8: MOSFETs, CMOS ICs Chapter 9: Convenient Uses of Voltage Sources and Current Sources Chapter 10: Differences in Models in SPICE Chapter 11: Subcircuit and Library Creation for Circuits and Models Chapter 12: Other Functions
