Automatic aggregation of power by equipment and line | CEW-M4 virtual sensor
Monitoring Software CEW-M4 | Hexacore Inc.
Automatically calculates the total and average values by performing arithmetic operations on multiple measurement values, categorized by equipment groups, production lines, and areas. This streamlines the aggregation process and equipment comparison.
When analyzing the power usage of a factory, relying solely on individual measurement values can make it difficult to grasp trends across the entire production line or equipment group. Additionally, transferring and aggregating data using spreadsheet software becomes increasingly burdensome as the volume of data grows. The virtual sensor function of the CEW-M4 allows for arithmetic operations on values obtained from multiple sensors, displaying and recording them as new measurement items. It can calculate total and average values by equipment group, line, floor, and area, which can be utilized for graph displays and alarm monitoring. 【Challenges】 - Want to understand the overall power usage of the line - Currently aggregating by equipment manually - Want to compare differences between equipment and lines 【Benefits of Implementation】 - Automatic calculation of total and average values - Reduction of manual data transfer, calculation, and aggregation tasks - Support for comparisons between equipment and before-and-after energy-saving measures For more details, please refer to the PDF document.
Inquire About This Product
basic information
Supported Operations: Addition, Subtraction, Multiplication, Division Main Measurement Items: Current, Power, Energy, Temperature, Humidity, etc. Virtual Sensors: Up to 2,000 measurement items Physical Sensors: Up to 20,000 measurement items Main Utilization Features: List Display, Graph Display, Alarm Monitoring, CSV Output Supported Communication: Modbus/TCP, Modbus/RTU, etc. For more details, please refer to the PDF document or feel free to contact us.
Price information
Please contact us.
Delivery Time
Applications/Examples of results
【Purpose (Assumed)】 Aggregation of power consumption by production line Aggregation of measurement values by process and equipment group Calculation of total values by factory, building, floor, and area Calculation of average values for similar equipment Comparison of usage trends between equipment and lines Power aggregation by application such as air conditioning, lighting, and production equipment Verification of power usage during non-operating hours and while on standby Comparison of data before and after energy-saving measures implementation Verification of effects before and after equipment updates and operational changes Labor-saving of manual transcription, calculation, and aggregation Calculation of management indicators using temperature and humidity Alarm monitoring for calculated values Utilization of data towards the construction of a smart factory For more details, please download the PDF document or feel free to contact us.
catalog（1）
Download All Catalogs
Company information
HexaCORE Co., Ltd. (formerly Chuo Seisakusho Co., Ltd.) Head Office and Factory
Company profile: Hexacore Inc. designs, manufactures and sells telecommunications and data centre equipment, as well as measurement and monitoring systems. In a world moving towards sustainability, telecommunications and energy infrastructure remain essential to our daily lives. Hexacore offers solutions that support the construction of safe and efficient communication facilities, promoting energy efficiency and backed by technical expertise and a customer-oriented support system. Notice: Please note that, effective 1 April 2023, our company name was changed from Chuo Seisakusho Co., Ltd. to Hexacore Inc.
