Overcoming the weakness of fluororesin "scratches." High hardness ceramic coating "Biceram 100" that prevents adhesion of high-viscosity varnishes and adhesives.
Generally, "fluororesin coating" is widely used for non-stick and release purposes, but due to the softness of the coating film, using scrapers or spatulas during cleaning can damage the film, leading to wear and peeling. ■Features of Biceram 100 It is a high-performance surface treatment technology that forms a dense and hard coating based on ceramic components, achieving excellent non-stick properties and high coating hardness that surpass fluororesins. ■Prevention of scratches with the high hardness surface unique to ceramics Not only does it physically reduce the strong adhesion of high-viscosity resin varnishes and adhesives to the tank inner walls and receiving pans, but the coating is also less prone to scratches during cleaning with tools, allowing the initial excellent release effect to last for a long time. Additionally, it excels in chemical resistance and heat resistance against cleaning solvents, strongly supporting the longevity of equipment and maintenance-free operation in harsh industrial environments.
Inquire About This Product
basic information
**[Technical Brand]** Ceramic Coating "Biceram 100" **[Key Specifications and Features]** ■ High Durability Ceramic Coating The hard ceramic components effectively suppress scratches caused by abrasion from cleaning tools and physical contact. ■ Ultra-Low Surface Energy Surface characteristics that make it difficult for high-viscosity, strong-adhesion resin varnishes and paints to adhere. ■ Excellent Chemical and Heat Resistance Stable chemical properties that are not compromised by resin varnishes or maintenance cleaning solvents. *Note: Non-stick performance may decrease with certain organic solvents (mainly non-polar solvents) such as xylene, toluene, and hexane. ■ PFAS Free Safety design that does not contain environmentally harmful substances (organic fluorine compounds). **[Compatible Substrates and Shapes]** General metal parts such as stainless steel and steel materials (inner surfaces of tanks, drip trays, hoppers, chutes, stirring components, etc.) *For processes where siloxane-free is essential, we can also propose alternative coatings that are optimally suited.
Price range
Delivery Time
Applications/Examples of results
【Applicable Industries】 ■Automotive/Transportation Equipment Components for varnish impregnation devices for motor coils and electrical equipment ■Semiconductors/Electronic Components Transport and storage containers for insulating sealing materials for substrates and packages ■Chemical Industry Manufacturing and application equipment for high-viscosity paints, adhesives, and resin materials 【Case Study of Problem Solving】 ■Problem During the cleaning of tanks for strong adhesive varnish, the fluororesin coating was peeling off due to scraping with a spatula, resulting in dual challenges of rework costs and cleaning labor. ■Countermeasure Changed specifications to "Biceram 100," which combines wear resistance and release properties. ■Effect Even when workers clean with spatulas, the coating is no longer damaged, significantly extending the lifespan of the coating. This achieved simultaneous reductions in rework frequency (running costs) and downtime.
