Silicone-based materials are not used, and electronic components and circuit boards that are susceptible to outgassing are thoroughly protected under a chemical atmosphere.
The fluorine rubber-based chemical-resistant coating Eight Seal "FN-202 Series" is a protective coating agent with the following features: 【Features】 〇 Compatible with various environments including chemicals It has excellent chemical resistance (to acids, alkalis, and peroxides), heat resistance (up to about 200°C), and barrier performance, protecting substrates from failures of electronic devices due to humidity (such as condensation) and corrosive gas atmospheres. (It does not have heat insulation effects.) 〇 Non-silicone In electronic materials, silicone materials are to be avoided in contact. This product is based on fluorine rubber and does not use any silicone-based materials, making it suitable as a protective coating for electronic components. 〇 Easy to use one-component paint Various application methods such as brushing and dipping are possible, and after application, it can form a protective film simply by air drying at room temperature. 〇 Customizable film thickness according to application The Eight Seal "FN-202 Series" offers two varieties with different viscosities. You can choose a product that suits your application.
Inquire About This Product
basic information
< FN-202X > Appearance: Light yellow to slightly cloudy color* Viscosity: 350 mPa·s at 25℃ Packaging: 500g can, 15kg can < FN-202XH > Appearance: Light yellow to slightly cloudy color* Viscosity: 50,000 mPa·s at 25℃ Packaging: 330g cartridge *(When applied, it forms a thin film, so the color is not very noticeable) - Instructions for Use 1. Remove any dust, rust, etc. from the area to be painted and clean the application surface. 2. If necessary, mask off areas such as electrical contacts and apply using a brush or by dipping. 3. Allow to dry thoroughly in a well-ventilated area without trapping air. (It is best to leave it for one full day and night) *Flammable organic solvents are used. Please be careful not to bring any flames close during use, and ensure that you are in a well-ventilated environment.
Price information
Please contact the sales department.
Delivery Time
Applications/Examples of results
- Protection of electronic substrates and materials from chemical atmospheres (acids, alkalis, peroxides) - Corrosion and rust prevention for metal and non-ferrous metal parts - Corrosion and rust prevention in high-temperature environments
