Juralon spacer for vertical board mounting / VAD
This product is a dedicated spacer designed to mount circuit boards vertically, made from Duracon (POM), which boasts mechanical strength and high dimensional stability. By arranging sub-boards and sensor boards vertically relative to the main board, it allows for three-dimensional utilization of the limited space inside the enclosure, strongly supporting the implementation of high-density electronic devices. The Duracon material has very low water absorption, resulting in minimal dimensional changes and warping even in humid environments, accurately maintaining the angle of vertically mounted circuit boards over long periods. Additionally, it possesses complete electrical insulation, physically preventing the risk of shorts between the circuit boards and the enclosure or adjacent circuits, ensuring safe implementation. In environments that pursue space-saving designs, this is a highly efficient option that enables a three-dimensional layout by standing the circuit boards. It achieves reliable fixation and insulation in designs aimed at miniaturizing equipment and optimizing internal structures.
Inquire About This Product
basic information
■Specifications - Material: Duracon (POM) - Color: Milky white - Heat distortion temperature: 1.82MPa…110℃ - UL standard: UL94-HB (material) ■Size variations - Screw diameter: for M2 / for M2.6 / for M3 / for M4 ■EU-RoHS - Compliant with EU-RoHS2
Price information
For more details, please check our website or catalog, or feel free to contact us.
Delivery Time
Applications/Examples of results
We offer a variety of products that can be used for various applications such as printed circuit board assembly, electronic component assembly, semiconductor assembly, relay terminal assembly, distribution board components, robot parts, industrial machinery, machine tool parts, water treatment machinery parts, FA equipment, mobile communications, mobile mobility, and base station-related components.
