Please consult us about the small diameter hole of the orifice nozzle. We will check the hole diameter and depth, tolerances, and the condition of the inlet and outlet, and consider the processing method using fine hole discharge.
At Hanshin Seiko, we accept inquiries regarding the machining of fine holes and small diameter holes necessary for orifice, nozzle, and flow path components. We have equipment capable of fine hole electrical discharge machining starting from φ0.3mm, and we consider machining small diameter holes that are difficult to process with drills, as well as holes in high-hardness materials such as hardened steel. The feasibility of machining is determined by checking not only the hole diameter but also the combination of material, plate thickness, hole depth, and required precision. In orifices, the hole diameter tolerance, effective length of the hole, and the shape and condition of the inlet and outlet are important. We also confirm the necessary roundness and surface roughness, and consider machining and inspection methods according to the required specifications. We also consider responding to prototypes with different hole diameters, machining multiple holes, and adding holes to supplied parts. If machining of outer shapes, seating surfaces, or reference surfaces is required, please consult us about processes that combine machining, wire cutting, and polishing. Along with the drawings, please provide information on material, hole diameter and tolerance, hole depth, number of holes, quantity, intended use, and desired delivery date.
Inquire About This Product
basic information
Processing targets: Orifices, nozzles, flow path components, etc. Processing details: Fine holes, small diameter holes, multiple holes, additional holes to supplied parts Main processing method: Fine hole electrical discharge machining Available equipment: Equipment capable of fine hole electrical discharge machining from φ0.3mm Verification items: Conductivity, material, hardness, hole diameter and tolerance, hole depth and effective length, plate thickness, hole position and pitch, entrance and exit shape, roundness and surface roughness *Note: φ0.3mm refers to equipment specifications and does not guarantee finished hole diameter or accuracy for all materials and depths. In some cases, fine hole electrical discharge machining alone may not be sufficient to meet requirements.
Price information
This is an individual estimate for each drawing. We will confirm the material, hardness, hole diameter, depth, number of holes, hole positions, required tolerances, specifications for entrance and exit, quantity, and processing range of surrounding shapes to provide the estimate.
Delivery Time
※We will confirm the hole diameter and depth, number of holes, quantity, required precision, necessary processing steps, and equipment operating status. Please let us know the planned delivery date and desired delivery date.
Applications/Examples of results
【Applications and Consultation Examples】 - Orifice components used for flow adjustment and pressure control - Fine holes in nozzles and flow path components - Addition of small diameter holes to parts after hardening - Hole processing where drill wear or breakage is an issue - Prototype parts for comparative evaluation with different hole diameters - Multiple hole processing on the same part - Addition of holes to supplied parts that have already been machined - Outsourcing of fine hole discharge processes only *This is a contract processing service based on drawings. If there are specific flow characteristics or inspection requirements, please inform us during the processing consultation.
Company information
Hansei Seiko Co., Ltd. is a precision metal processing company founded in 1948, based in Kobe City, Hyogo Prefecture. We offer integrated processing services centered around wire cut electrical discharge machining, shape electrical discharge machining, and fine hole electrical discharge machining, as well as machining, polishing, finishing, and measurement. We welcome inquiries for precision parts, mold components, jigs, test pieces, and more, whether for single items, prototypes, or small lots. In addition to processing hardened steel, carbide, and stainless steel, we also handle contour machining of thick parts, key grooves, fine slits, and complex shapes. We confirm material, shape, required precision, and application, and consider processing conditions and processes. This reduces the burden of arranging multiple processing locations and supports part manufacturing. Based on the principle of "making according to the drawings," we conduct inspections and measurements in-house to confirm the finish before shipping. Based in Kobe and Hyogo, we accept processing inquiries and quotation requests from across the country. If you have parts you are struggling to process or drawings for which you would like to consider methods and processes, please feel free to consult with us. https://www.hansei.co.jp/
