Metal mask laser processing machine
The opening size of metal masks has become smaller, and the printing of solder paste is becoming increasingly precise. This can be attributed to the advancements in stencil technology. The LPKF Stencil Laser G6080, which achieves superiority in speed, precision, safety, and both initial and running costs, is a metal mask laser processing machine that leads the industry. The LPKF Stencil Laser G6080 is designed with the concept of achieving high productivity at minimal cost while maintaining high quality. Its excellent design and high productivity have earned it high praise from customers around the world. Until now, cooling equipment that was necessary for operating metal mask laser processing machines has become unnecessary. This not only saves space but also reduces running costs. In addition to the MicroCut6080, which specializes in small hole processing with a minimum incident diameter of 18um (output 10um), we offer the PowerCut6080, capable of precision processing parts up to a maximum thickness of 4mm, as well as processing non-stainless materials such as copper and aluminum, contributing to the development of our customers.
Inquire About This Product
basic information
【Features】 ○ Main body size (L×W×H) 2000×2000×2000 mm Main body weight approximately 2000Kg Power consumption approximately 2.5kw (only for the machine body. Power for support equipment is not included.) ○ Maximum frame size (X/Y) 740×950 mm Processing range (X/Y) 600×800 mm Material thickness maximum 600μm ○ Position accuracy (X/Y axis) ±2μm (at room temperature 20℃, ±0.5℃) Repeatability accuracy ±2μm Minimum processing hole size: 30μm ● For other functions and details, please contact us.
Price information
Please feel free to contact us.
Delivery Time
※Please feel free to contact us.
Applications/Examples of results
【Usage】 ○ Mainly used for SMT metal mask manufacturing. ○ Used for wafer bumping and precision machine parts processing. ● For other functions and details, please contact us.
Line up（3）
| Model number | overview |
|---|---|
| LPKF SL G6080 | SMT metal mask laser processing machine. World-class throughput. High reliability and quality based on proven results. |
| LPKF MicroCut6080 | Of course, SMT metal masks, and a laser processing machine further enhanced for thin plates and small diameter areas. Suitable for processing wafer bumps, deposition masks, etc. |
| LPKF PowerCut6080 | Of course, SMT metal masks, and a laser processing machine that enables processing of various types and up to 4mm thick stainless steel. Suitable for precision parts processing of stainless steel, nickel, copper, aluminum, and more. |
