Quickly and gently secure the outer diameter of small workpieces using the inclined friction surface of a wooden collet. A lightweight fixture that can be produced with a 3D printer.
This product is a friction-holding fixture that uses the inclined surface of a wooden collet to retain the outer diameter of small workpieces. The base fixture can be produced with a 3D printer, enabling lightweight tooling without metal machining. It can be manufactured at low cost and in a short lead time, and is suitable for a wide range of applications from prototyping and assembly to inspection and educational use. The wooden collet body can be manufactured by our company, and we can also provide consultation on 3D printer data for the fixture. A 3D-printed sample unit is available; please contact us if you would like a demonstration.
Inquire About This Product
basic information
Applicable workpieces: Outer diameter retention only (for workpieces around φ35 mm or 25 × 25 mm) Size: Approx. φ68 mm × height 50 mm Weight: Approx. 200 g Material: 3D-printed body (PLA / ABS) Price: Quotation based on specifications (small-lot and prototype orders supported)
Price information
3D-printed fixture: Reference price 11,800 JPY (excluding tax) per unit for standard specifications (custom designs up to around 12,800 JPY). Wooden forming die set: Reference price 250,000 JPY (excluding tax) per set. Medium-size replacement insert for wooden die: Reference price 30,000 JPY (excluding tax) (25,000 JPY for the replacement part + 5,000 JPY for design fee).
Price range
P2
Delivery Time
P4
Applications/Examples of results
Fixture for small parts (assembly, inspection, bonding processes) Used as a holding platform for prototype development and research purposes Can also be utilized as an educational material for 3D printer training Can be used as a stand for exhibitions and photography
Detailed information
-
Cross-sectional view of the wooden collet fixture showing the inclined friction surface for outer diameter retention.
catalog（2）
Download All Catalogs
CAD data（2）
| Model number | overview | File |
|---|---|---|
| Outline drawing <PDF> |
|
|
| Outline drawing <DXF> |
|
