The pinholes in aluminum coating are caused by insufficient drying. It is important to treat the surface to allow internal moisture to escape.
Pinholes that occur in aluminum products can sometimes be caused by moisture remaining on the surface or inside the material. Special attention is needed, particularly after machining or insufficient drying following cleaning. During baking, moisture evaporates and can push up the coating, resulting in tiny holes. Aluminum has a high thermal conductivity, causing the surface temperature to rise rapidly, which can prevent internal moisture from escaping. The risk of occurrence increases, especially with a film thickness of 40μm or more. Measures to address this include pre-drying at 60-80°C and managing the storage environment before painting. Additionally, care must be taken to prevent moisture re-adhesion in environments with humidity above 70%. We also provide detailed examples of improvements specific to aluminum materials in our published materials.
