What is the cause of only the first batch of products in the morning being defective? Furnace startup.
Only a few defects occur right after the start of operations. I will explain the management methods until the furnace and booth reach a steady state.
Only a few pieces right after starting production consistently have defects. The operators are the same. The difference is the temperature of the equipment. ────────────── ■ Cause of Occurrence Both the curing furnace and the booth are not stable immediately after startup from a stop. Even if the displayed temperature reaches the set point, the furnace walls and jigs remain cold. ■ Truth When the furnace walls are cold, they draw heat from the product, lowering the actual curing temperature. Until the booth's air conditioning stabilizes, the humidity is also high, making defects more likely. The recorded temperature reflects the set value, so the cause remains unidentified and repeats. ■ Improvement Measures Decide on a pre-heating time before starting production and preheat each jig before running them through. For the first few pieces, only run waste boards or jigs, and once conditions stabilize, proceed with the main flow. Please utilize the standardization materials for the startup procedure.
Inquire About This Product
Related Videos
basic information
Corresponding construction method: solvent-based baked coating, powder coating / Baking temperature: 140-200 degrees / Startup management: setting empty burning time, jig preheating, initial product confirmation / Records: management of furnace wall temperature and actual product temperature / Inspection: confirmation of all initial products
Price range
Delivery Time
Applications/Examples of results
Quality control of a painting line with multiple varieties and small lot production, which stops the furnace daily. We have a track record of supporting the standardization of preheating time and waste flow in response to concentrated defects right after the start of operations.
