The surface of the received painted item is sticky and sticks together when stacked. The cause is insufficient baking temperature or time. Here is a simple confirmation method that can be done upon receipt.
When touching the received painted parts, the surface feels slightly sticky. When stacked, the parts stuck to each other. 【Checks to Perform Upon Receipt】 □ Pressing with a fingernail leaves a mark → The paint film has not fully cured □ Rubbing with a cloth soaked in thinner transfers color → The baking temperature or time was insufficient □ Only the thick parts are sticky → The baking process finished before the parts were fully heated 【Why This Happens】 Baked paint only hardens at the specified temperature and time. Even if the oven settings are correct, it will not cure if the temperature of the parts has not increased. 【Countermeasures to Implement Starting Today】 1. Request records of baking temperature and time from the subcontractor 2. Perform rub checks randomly upon receipt 3. For thick parts, have separate baking conditions established 【Free Resource】 The management standards for baking conditions are compiled in the related catalog "Eiwa Kogei_Paint Quality Control Guidelines_Process Management Standards." This can be downloaded for free from this page.
Inquire About This Product
Related Videos
basic information
Defect type: Poor hardening (stickiness). Verification method: Press with a nail, rub with a cloth soaked in thinner. Management items: Curing temperature and time, thickness of the parts.
Price range
Delivery Time
Applications/Examples of results
Acceptance inspection of painted products, confirmation of processes at subcontractors, handling complaints regarding curing defects. Materials for training new sales representatives and quality assurance personnel.
