When high-temperature baking of fluororesin coating is not possible.
This is a PTFE coating that can form a film at a low temperature of about 180°C due to the binder being epoxy resin. It can be used on materials that cannot withstand high temperatures, even if you want to coat them with fluororesin.
Inquire About This Product
basic information
- Appearance: Black, White, Clear - Hardness: H (pencil hardness) - Standard film thickness: 20µm - Heat resistance temperature: Approximately 150℃ - Release property: Good (after heating at 150℃ for 30 minutes with drops of egg, sauce, ketchup, sugar, etc., it can be easily removed with a damp cloth) - Corrosion resistance: No abnormalities after 100 hours of salt spray test - Boiling water resistance: No abnormalities after immersion in boiling water at 90℃ or higher for 100 hours - Acid resistance: No abnormalities after immersion in 10% sulfuric acid solution for 16 hours - Solvent resistance: No abnormalities after immersion in xylene for 16 hours - Static friction coefficient: 0.10 to 0.14 (reference value) - Dynamic friction coefficient: 0.07 to 0.10 (reference value) - Dielectric strength (excluding black): Approximately 1000V at a film thickness of 20µm (reference value for test specimen)
Price range
Delivery Time
※Delivery times may vary depending on the quantity. If you are in a hurry, we can accommodate shorter delivery times, so please consult with us.
Applications/Examples of results
- Sliding parts, guide components: Reduction of metal wear due to low friction coefficient and enhancement of sliding properties - Conveying chutes, hoppers, jigs: Prevention of sticking and adhesion of powders and adhesives (release and anti-soiling) - Kitchen equipment, components in corrosion-resistant areas: Parts made of aluminum or stainless steel that require resistance to boiling water, corrosion, and acids - For areas requiring insulation (only in white and clear colors)
catalog（1）
Download All Catalogs
Company information
Sawaheira Co., Ltd. has been building deep trust with everyone since its establishment in 1959 as a company capable of consistently handling everything from machining and pressing of machine parts to various coatings and assembly work. Our company contributes to cost reduction by being able to manufacture machine parts consistently, and we have also strived to be of service to everyone with our advanced technology and reliable quality control in cutting-edge precision machining, metal processing technology, and functional coating technologies such as fluororesin and molybdenum disulfide. Moving forward, we are committed to further advancing "technology development" and "quality control" to meet our customers' needs.
